Technical Specifications
| Parameter | Value |
|---|---|
| Range of Product | Modicon Momentum automation platform |
| Product or Component Type | M1/M1E Processor Adaptor |
| Software Compatibility | Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, ProWORX 32 |
| Communication Port Protocol | Modbus |
| Processor Type | x86-based (INTEL, AMD) |
| Clock Frequency | 20 MHz |
| Word Length | 16-bit |
| Memory Type | 256 kB Flash, 64 kB RAM |
| Memory Description | Program: 2.4 kB LL984, Data: 2 kB |
| Discrete I/O Processor Capacity | 2048 Inputs / 2048 Outputs |
| Register I/O Processor Capacity | 2048 Inputs / 2048 Outputs |
| Communication Port | 1 × RS232C non-isolated |
| Supply Voltage [Us] | 5.0 V DC ±5% |
| Power Supply | Supplied by Momentum I/O base |
| Instruction Execution Time | 1 ms per 1K instruction |
| Material | Lexan |
| Protective Treatment | TC |
| Marking | CE |
| Product Certifications | UL, cUL, FM Class 1 Div 2, NEMA Type 250 |
| Operating Temperature Range | 32 to 140 °F (0 to 60 °C) |
| Storage Temperature Range | -40 to 185 °F (-40 to 85 °C) |
| Relative Humidity | 5 to 96%, non-condensing |
| Operating Altitude | Up to 2000 m (6561.68 ft) |
| Shock Resistance | ≤ 15 g, 11 ms half sine wave |
| Vibration Resistance | 0.75 mm (displacement amplitude), 1 g |
| Dimensions (W × H × D) | 53 × 177 × 258 mm |
| Net Weight | 0.042 kg (0.093 lb) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the 171CCS70000 processor adaptor?
A1: It serves as a processor module for Modicon Momentum systems, providing Modbus communication and handling logic execution.
Q2: Which software platforms are compatible with this adaptor?
A2: It is compatible with Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, and ProWORX 32.
Q3: What is the memory capacity of this module?
A3: It has 256 kB of flash memory, 64 kB of RAM, 2.4 kB for the program (LL984), and 2 kB for data.
Q4: What type of processor is integrated in the module?
A4: It uses an x86-based processor, compatible with INTEL or AMD architecture.
Q5: How is the module powered?
A5: The module receives power directly from the Momentum I/O base.
Q6: What kind of communication port does it use?
A6: It features a single non-isolated RS232C port.
Q7: What are the operating environmental limits for this product?
A7: It operates between 0 to 60°C and can be stored from -40 to 85°C with up to 96% humidity without condensation.
Q8: What certifications does this module hold?
A8: It is certified by UL, cUL, FM Class 1 Division 2, and complies with NEMA Type 250.
