Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric ATV310HU40N4A |
| Model / Part Number | ATV310HU40N4A |
| Product Series | Altivar 310 Easy Variable Frequency Drive (VFD) |
| Product Type | Three-phase AC motor speed controller (VFD) |
| Rated Motor Power (Normal Duty) | ≈ 5.5 kW (≈ 7.5 hp) |
| Rated Motor Power (Heavy Duty) | ≈ 4 kW (≈ 5 hp) |
| Supply Voltage | 380–460 VAC, three-phase |
| Supply Frequency | 50/60 Hz |
| Rated Output Current | ≈ 14–18 A |
| Output Frequency Range | ≈ 0.5 – 400 Hz |
| Control Methods | V/f and sensorless flux vector control (typical) |
| Communication | Modbus RTU over RS-485 (RJ45) |
| EMC Filter | Without built-in EMC filter |
| Protection Rating | IP20 (indoor industrial use) |
| Cooling | Integrated fan cooling |
| Approvals / Standards | IEC/EN 61800-5-1, IEC/EN 61800-3 (common for series) |
| Mounting | Vertical panel mount (± 10°) |
| Dimensions (W × H × D) | 140 mm × 184 mm × 151 mm |
| Net Weight | ≈ 1.8 kg |
| Typical Use | Speed and torque control of three-phase motors in industrial and OEM applications (e.g., pumps, conveyors, fans) |
FAQ
FAQ
Q1: What is the primary purpose of this VFD?
It is a compact variable frequency drive used to control the speed and torque of three-phase AC motors by adjusting the output frequency and voltage for energy-efficient operation.
Q2: What motor power rating does the ATV310HU40N4A support?
This model supports up to approximately 5.5 kW (7.5 hp) normal duty and 4 kW (5 hp) heavy duty motors.
Q3: What supply voltage and frequency does this drive require?
It operates on a 380–460 VAC, three-phase supply with a 50/60 Hz power frequency.
Q4: What range of output frequencies can this VFD provide?
The drive can vary its output frequency from approximately 0.5 Hz up to around 400 Hz.
Q5: What communications interface does it include?
It supports Modbus RTU communication over an RS-485 (RJ45) connection, allowing integration with PLCs and automation systems.
Q6: Does the ATV310HU40N4A include an EMC filter?
No — this model does not include a built-in EMC filter, which can simplify installation but may require external filtering in environments sensitive to electromagnetic interference.
Q7: What are the physical dimensions of this variable frequency drive?
The unit measures approximately 140 mm wide × 184 mm high × 151 mm deep.
Q8: How much does the ATV310HU40N4A weigh?
The net weight of the drive is about 1.8 kg.
