Technical Specifications
| Parameter | Description |
|---|---|
| Model | ATV610D18N4 |
| Type | Speed Driver / VFD |
| Voltage | 3 Phase 380–480 V AC |
| Output Power | 18 kW |
| Output Current | 35 A |
| Frequency Range | 0–500 Hz |
| Control Method | V/F Control / Vector Control / Closed-loop Speed |
| Input Power | 3 Phase AC |
| Communication | Modbus RTU / CANopen / Ethernet / Profibus optional |
| Protection | IP21 (IP54 optional) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions | 211 x 580 x 232 mm |
| Weight | 13.5 kg |
FAQ
FAQ
Q1: What is the output power of the driver?
A1: The output power is 18 kW.
Q2: What is the supported input voltage range?
A2: 380–480 V AC three-phase.
Q3: What is the operating temperature range?
A3: -10°C to +50°C.
Q4: Which control methods are supported?
A4: Supports V/F control, vector control, and closed-loop speed control.
Q5: What is the protection rating of the driver?
A5: Standard IP21, optional IP54.
Q6: Does it support communication interfaces?
A6: Yes, supports Modbus RTU, CANopen, Ethernet, and Profibus (optional).
Q7: What is the storage temperature range?
A7: -40°C to +70°C.
Q8: What are the dimensions and weight?
A8: Dimensions are 211 x 580 x 232 mm, weight 13.5 kg.
