Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | Schneider Electric ATV610U55N4 |
| Product Series | Easy Altivar 610 |
| Product Type | Variable Frequency Drive (VFD) |
| Rated Power | 5.5 kW (Normal Duty) / 4 kW (Heavy Duty) |
| Rated Horsepower | 7.5 HP (Normal Duty) / 5 HP (Heavy Duty) |
| Supply Voltage | 3-phase 380–460 V AC (-15% to +10%) |
| Supply Frequency | 50/60 Hz ±5% |
| Output Frequency Range | 0.1–500 Hz |
| Rated Output Current | 12.7 A (Normal Duty) / 9.3 A (Heavy Duty) |
| Maximum Transient Current (60 s) | 14 A (Normal & Heavy Duty) |
| Motor Control Methods | V/F Control, Sensorless Vector Control |
| Protection Rating | IP20 |
| Cooling Method | Forced Air Cooling |
| Built-in EMC Filter | Yes, IEC/EN 61800-3 Category C3 |
| Analog Inputs | 3 configurable analog inputs |
| Analog Outputs | 2 configurable analog outputs |
| Digital Inputs | 6 configurable digital inputs |
| Communication Interface | RS-485 (Modbus RTU) |
| Switching Frequency | Adjustable 2–12 kHz |
| Preset Speeds | 16 preset speeds |
| Dimensions (W × H × D) | 145 × 297 × 203 mm |
| Weight | Approx. 4.575 kg |
FAQ
Q1: What is the rated power of the ATV610U55N4?
The drive is rated at 5.5 kW (7.5 HP) for normal duty and 4 kW (5 HP) for heavy duty applications.
Q2: What supply voltage does this model operate on?
This VFD requires a three-phase supply between 380 V and 460 V AC.
Q3: What frequency range can the ATV610U55N4 output?
It can output a variable frequency from 0.1 Hz up to 500 Hz.
Q4: What motor control methods are supported?
Both V/F control and sensorless vector control are supported for motor speed regulation.
Q5: How many analog and digital inputs are available?
The drive offers 3 analog inputs and 6 digital inputs for flexible control.
Q6: Does the drive include an EMC filter?
Yes, an integrated EMC filter compliant with IEC/EN 61800-3 Category C3 is included.
Q7: What are the physical size and footprint of this unit?
The unit measures 145 × 297 × 203 mm, making it suitable for cabinet mounting.
Q8: How much does the ATV610U55N4 weigh?
The approximate weight of the drive is 4.575 kg.
如果你需要这个变频器在具体行业（比如水处理、HVAC、输送线）的典型应用案例说明，我也可以继续整理。
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | Schneider Electric ATV610U75N4 |
| Product Series | Easy Altivar 610 |
| Product Type | Variable Frequency Drive (VFD) |
| Rated Power | 7.5 kW (Normal Duty) / 5.5 kW (Heavy Duty) |
| Rated Horsepower | 10 HP (Normal Duty) / 7.5 HP (Heavy Duty) |
| Supply Voltage | 3-phase 380–460 V AC (-15% to +10%) |
| Supply Frequency | 50–60 Hz ±5% |
| Output Frequency Range | 0.1–500 Hz |
| Rated Output Current | 15.8 A (Normal Duty at 4 kHz) / 12.7 A (Heavy Duty at 4 kHz) |
| Maximum Transient Current (60 s) | 17.4 A (Normal Duty) / 19.1 A (Heavy Duty) |
| Motor Control Methods | Constant Torque Standard, Optimized Torque Mode, Variable Torque Standard |
| Protection Rating | IP20 |
| Cooling Method | Forced Convection |
| Built-in EMC Filter | Yes (IEC/EN 61800-3 Category C3 with 50 m) |
| Analog Inputs | 3 configurable analog inputs |
| Analog Outputs | 2 configurable analog outputs |
| Digital Inputs | 6 configurable digital inputs |
| Communication Interface | RS-485 (Modbus RTU) |
| Switching Frequency | Adjustable 2–12 kHz |
| Preset Speeds | 16 preset speeds |
| Dimensions (W × H × D) | 145 × 297 × 203 mm |
| Weight | Approx. 4.575 kg |
FAQ
Q1: What is the rated power of the ATV610U75N4?
The drive is rated at 7.5 kW for normal duty and 5.5 kW for heavy duty operation.
Q2: What input voltage does this model use?
It operates on a three-phase AC supply between 380 V and 460 V.
Q3: What frequency range can the ATV610U75N4 output?
The output frequency range is 0.1 Hz up to 500 Hz.
Q4: What types of motor control methods are supported?
It supports constant torque, optimized torque, and variable torque control profiles.
Q5: Does this VFD include EMC filtering?
Yes, an integrated EMC filter conforming to IEC/EN 61800-3 Category C3 is included.
Q6: What communication protocols does it support?
The drive provides RS-485 communication with Modbus RTU support.
Q7: What are the physical dimensions of this drive?
The drive measures 145 × 297 × 203 mm in width, height, and depth.
Q8: How heavy is the ATV610U75N4?
This model weighs approximately 4.575 kg.
如果还需要我整理其他型号或者应用场景问答说明，我也可以继续。
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | Schneider Electric ATV630D11N4 |
| Product Series | Altivar Process ATV630 |
| Product Type | Variable Frequency Drive (VFD) |
| Rated Power | 11 kW (Normal Duty) / 7.5 kW (Heavy Duty) |
| Rated Horsepower | 15 HP (Normal Duty) / 10 HP (Heavy Duty) |
| Supply Voltage | 3-phase 380–480 V AC (-15% to +10%) |
| Supply Frequency | 50–60 Hz |
| Output Frequency Range | 0.1–500 Hz |
| Rated Output Current | ~23.5 A (Normal Duty) / ~16.5 A (Heavy Duty) |
| Line Current at 380/480 V | 19.8/17.0 A (Normal Duty) / 14.1/12.5 A (Heavy Duty) |
| Switching Frequency | Nominal 4 kHz (adjustable) |
| Motor Control Modes | Constant torque, variable torque, optimized torque; supports synchronous & asynchronous motors |
| Protection Rating | IP21 / UL Type 1 |
| Safety Functions | Safe Torque Off (STO, SIL 3), overload, thermal and short-circuit protections |
| Cooling Method | Forced convection |
| Analog Inputs | 3 configurable |
| Analog Outputs | 2 configurable |
| Digital Inputs | 8 |
| Relay Outputs | 3 (alarm/fault/sequence) |
| Communications | Ethernet (Modbus TCP), Modbus RTU/serial; optional fieldbus modules |
| Dimensions (W × H × D) | 171 × 409 × 233 mm |
| Weight | Approx. 7.7 kg |
FAQ
FAQ
Q1: What is the rated power of this drive?
The drive delivers up to 11 kW under normal duty and 7.5 kW under heavy duty operation.
Q2: What supply voltage range does the ATV630D11N4 accept?
It operates from a three-phase 380–480 V AC supply.
Q3: What types of motors can this drive control?
It supports both asynchronous and synchronous motors with multiple control profiles including constant and optimized torque.
Q4: What is the output frequency range?
The output frequency ranges from 0.1 Hz up to 500 Hz for motor speed control.
Q5: What safety and protection features are integrated?
Integrated safety features include Safe Torque Off (STO), overload, thermal, and short-circuit protections.
Q6: What communication protocols are supported?
The drive has built-in Ethernet with Modbus TCP and Modbus RTU communication, with options for additional fieldbus modules.
Q7: What is the enclosure protection level?
This model has an IP21 protection rating and UL Type 1 enclosure for industrial applications.
Q8: What are the physical dimensions and weight of the unit?
The drive measures 171 × 409 × 233 mm and weighs approximately 7.7 kg.
