Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric BMEP582040S |
| Manufacturer | Schneider Electric |
| Product Series | Modicon M580 Safety |
| Product Type | Safety Processor Module |
| Processor Level | Level 2 |
| Safety Integrity Level | SIL3 |
| Safety Category | Category 4 |
| Application | Safety PLC / Process Control |
| Local Rack Capacity – Discrete I/O | 2,048 I/O |
| Local Rack Capacity – Analog I/O | 512 I/O |
| Number of Local Racks | 4 |
| Remote I/O Stations | Up to 8 |
| Remote I/O Racks | Up to 8 |
| Distributed Devices | Up to 64 |
| CIP Safety I/O Devices | Up to 16 |
| Ethernet Service Port | 1 × Ethernet TCP/IP |
| Device Network Ports | 2 × Ethernet TCP/IP |
| USB Interface | 1 × Mini-B USB |
| Ethernet Services | DIO Scanner / RIO Scanner |
| Application-Specific Channels | 72 |
| Program Memory | 8 MB |
| Data Memory | 768 kB |
| System Memory | 10 kB |
| Flash Memory | 4 GB expandable |
| Safety Program Memory | 2 MB |
| Safety Data Memory | 512 kB |
| Rated Supply | 24 VDC |
| Current Consumption | Approx. 295 mA @ 24 VDC |
| Mounting | DIN rail / backplane |
| Protection Rating | IP20 |
| Operating Temperature | -25°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Safety Certification | IEC 61508 / SIL3 |
| Approvals | CE, UL, CSA, EAC, TÜV and others |
| Dimensions | 64 × 130 × 135 mm (W × H × D) |
| Product Weight | Approx. 0.85 kg |
| Shipping Weight | Approx. 0.88 kg |
| Country of Origin | France |
FAQ
FAQ
Q1: What is the Schneider Electric BMEP582040S used for?
A: It is a Modicon M580 Safety processor module used for safety-critical PLC and industrial automation applications.
Q2: What safety level does the BMEP582040S support?
A: It is a Level 2 safety processor designed for applications up to SIL3 and Category 4 safety requirements.
Q3: How many local I/O points can it support?
A: It supports up to 2,048 discrete I/O points and 512 analog I/O points on the local rack.
Q4: How many remote I/O stations can the BMEP582040S support?
A: It can support up to 8 remote I/O stations, with up to 8 remote racks in the specified configuration.
Q5: What communication interfaces are available?
A: It provides 1 Ethernet TCP/IP service port, 2 Ethernet TCP/IP device-network ports and 1 Mini-B USB port.
Q6: What memory capacity does the BMEP582040S have?
A: It includes 8 MB program memory, 768 kB data memory, 10 kB system memory and 4 GB expandable flash storage. The safety memory includes 2 MB for safety programs and 512 kB for safety data.
Q7: What power supply does the BMEP582040S require?
A: It operates from a 24 VDC supply, with a specified consumption of approximately 295 mA at 24 VDC.
Q8: What are the dimensions and weight of the BMEP582040S?
A: The processor measures approximately 64 × 130 × 135 mm (W × H × D) and weighs approximately 0.85 kg.
