Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider BMXD06402K |
| Type | Digital Output Module |
| Product Category | Distributed I/O module |
| Product Family | Modicon BMX / M340 automation system |
| Output Type | DC discrete transistor outputs |
| Number of Outputs | 64 outputs |
| Output Voltage Range | 24 V DC nominal |
| Maximum Output Current | 0.25 A per output |
| Total Load Current | Up to 16 A (aggregate) |
| Output Logic | Positive logic (sourcing) |
| Status Indication | Individual LEDs for each output channel |
| Isolation | Channel‑to‑channel and channel‑to‑backplane isolation |
| Protection Features | Short‑circuit and overload protection |
| Mounting Method | DIN rail or BMX base mounting |
| Field Wiring Connection | Screw terminal connectors |
| Operating Temperature Range | 0 °C to +60 °C |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | BMX distributed I/O system and M340 controllers |
| Housing Material | Industrial‑grade plastic and metal contacts |
| Protection Rating | IP20 |
| Dimensions | Approx. 130 mm × 90 mm × 58 mm |
| Weight | Approximately 0.52 kg |
FAQ
FAQ
Q1: What is the primary function of the BMXD06402K module?
It provides 64 discrete DC output channels for controlling loads such as actuators, indicators, and relays in industrial automation systems.
Q2: What output voltage range does the BMXD06402K support?
The module supports a nominal 24 V DC output voltage.
Q3: How many output channels are on the BMXD06402K?
It has 64 discrete DC output channels.
Q4: What is the maximum current per output channel?
Each output channel can handle up to 0.25 A of load current.
Q5: Does the module provide status indication?
Yes, each output channel has an individual LED indicator showing its ON/OFF status.
Q6: Can this module be used in industrial environments?
Yes, it is designed for industrial automation and control cabinet installations.
Q7: How are outputs connected to field devices?
Outputs are connected via screw terminal connectors for secure and reliable wiring.
Q8: What are the physical dimensions and weight of the BMXD06402K?
The module measures approximately 130 mm × 90 mm × 58 mm and weighs around 0.52 kg.
