Technical Specifications
| Parameter Category | Description |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Backplane |
| Number of Slots | 4 bus slots |
| Compatible Products | BMXP34 processor, BMXCPS power supply, I/O modules, specific function modules |
| Power Consumption | 1.12 W |
| Electrical Connection | 1 XBE expansion module connector |
| Mounting Mode | By 4 M4/M5/M6 screws (panel or mounting plate) or 35 mm DIN rail clips |
| Dimensions (W x H x D) | 242.4 x 103.7 x 19 mm |
| Weight | 0.63 kg (approximately 1.39 lb) |
| Degree of Protection | IP20 |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Relative Humidity | 10% to 95%, non-condensing |
| Directives | 2014/35/EU (Low Voltage), 2014/30/EU (EMC) |
| Certifications | CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy |
| Standards Compliance | EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201, IACS E10, EN/IEC 61000-6-5 (Type 1/2), EN/IEC 61850-3 (Location G) |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many modules can the BMXXBP0400 backplane support?
A1: It supports up to 4 modules via 4 bus slots.
Q2: Is DIN rail mounting mandatory for the BMXXBP0400?
A2: No, it can also be mounted using screws on a panel or a mounting plate.
Q3: Which processors are compatible with the BMXXBP0400?
A3: It is compatible with Modicon X80 BMXP34 processors.
Q4: What is the power consumption of the backplane?
A4: The backplane consumes up to 1.12 W.
Q5: What is the operating temperature range of this backplane?
A5: It operates between 0°C and 60°C (32°F to 140°F).
Q6: Is the BMXXBP0400 suitable for marine applications?
A6: Yes, it complies with IACS E10 standard, making it suitable for maritime environments.
Q7: What certifications does the module meet?
A7: It is certified with CE, UL, CSA, RCM, EAC, UKCA, and Merchant Navy standards.
Q8: Can the BMXXBP0400 operate in high-EMI industrial environments?
A8: Yes, it complies with EN/IEC 61000-6-5 and EN/IEC 61850-3, suitable for EMI-prone areas.
