Technical Specifications
| Parameter | Value |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Backplane |
| Number of Slots | 8 bus X |
| Product Compatibility | BMXP34 processor, BMXCPS power supply, I/O modules, specific application modules |
| Power Consumption | 2.21 W |
| Electrical Connection | 1 connector (XBE) for expansion module |
| Mounting Mode | 4 x M4/M5/M6 screws on panel or mounting plate, or 35 mm DIN rail clips |
| Dimensions (H x W x D) | 103.7 x 372.8 x 19 mm |
| Weight | 0.95 kg (2.09 lb) |
| IP Degree of Protection | IP20 |
| Operating Ambient Temperature | 0 to 60°C (32 to 140°F) |
| Relative Humidity | 10% to 95% non-condensing |
| Directives | 2014/35/EU (Low Voltage Directive), 2014/30/EU (EMC Directive) |
| Product Certifications | CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy |
| Compliance Standards | EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201, IACS E10, EN/IEC 61000-6-5, EN/IEC 61850-3 (location G) |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many modules can the BMXXBP0800 backplane support?
A1: It supports up to 8 modules, including processor, power supply, I/O, and application-specific modules.
Q2: Is DIN rail mounting supported?
A2: Yes, it supports 35 mm symmetrical DIN rail mounting and screw-based panel mounting.
Q3: What is the power consumption of this backplane?
A3: The power consumption is 2.21 W.
Q4: Does it support expansion connectivity?
A4: Yes, it includes one XBE connector for expansion modules.
Q5: What is the operational temperature range?
A5: The operating temperature range is from 0 to 60°C (32 to 140°F).
Q6: What level of ingress protection does it have?
A6: It has an IP20 protection rating, suitable for cabinet use.
Q7: What are the product dimensions?
A7: The dimensions are 103.7 mm (H) × 372.8 mm (W) × 19 mm (D).
Q8: Does the BMXXBP0800 have international certifications?
A8: Yes, it is certified with CE, UL, CSA, RCM, EAC, UKCA, and Merchant Navy standards.
