Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Model Number | HMIDT952 |
| Product Type | Touch Smart Display (HMI Panel) |
| Product Range | Harmony GTU |
| Display Size | 18.5-inch widescreen |
| Display Type | Colour TFT LCD |
| Display Resolution | 1366 × 768 pixels (FWXGA) |
| Touch Technology | Multi-touch projected capacitive technology (PCT), up to 50 million touch cycles |
| Touchscreen Resolution | 2048 × 2048 |
| Display Colors | 16 million colors |
| Backlight Life | Approximately 50,000 hours |
| Rated Supply Voltage | 12–24 V DC |
| Supply Voltage Limits | 10.8–28.8 V DC |
| Power Consumption | 19 W |
| Inrush Current | 30 A |
| Integrated Ports | USB 2.0 Type-A, USB 2.0 Mini-B |
| Cooling Method | Natural convection |
| Installation Type | Indoor panel mounting |
| Panel Cut-out Dimensions | 465 mm × 319 mm |
| Product Dimensions (W × H × D) | 483 mm × 337 mm × 69 mm |
| Net Weight | 6.8 kg |
| Protection Rating | Front panel IP66 / IP67, NEMA 4X |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | −20 °C to 60 °C |
| Certifications | CE, CULus, KC, RCM |
| Compliance Standards | UL 508, ANSI/ISA 12-12-01, CSA C22.2 No 142, CSA C22.2 No 213, IEC 61131-2 |
| Typical Applications | Industrial automation, machinery control, food & beverage processing, water treatment, mining, packaging systems |
FAQ
FAQ
Q1. What is the HMIDT952 used for?
It is an industrial HMI touch display designed to connect with automation controllers and provide operators with graphical monitoring and control of machines or production processes.
Q2. What screen size and resolution does the display provide?
The panel features an 18.5-inch TFT LCD display with a resolution of 1366 × 768 pixels (FWXGA).
Q3. What type of touch technology does this HMI use?
It uses projected capacitive multi-touch technology capable of about 50 million touch cycles.
Q4. What power supply does the HMIDT952 require?
The unit operates on a 12–24 V DC power supply with allowable limits between 10.8 V and 28.8 V DC.
Q5. What are the physical dimensions and weight of the device?
The display measures 483 mm × 337 mm × 69 mm and weighs approximately 6.8 kg.
Q6. What environmental protection level does the panel provide?
The front panel is rated IP66/IP67 and NEMA 4X, providing protection against dust and water in industrial environments.
Q7. What communication or connection interfaces are available?
It includes integrated USB 2.0 Type-A and USB 2.0 Mini-B ports for peripheral connections and configuration.
Q8. What industries commonly use the HMIDT952?
It is commonly applied in industrial automation sectors such as manufacturing machinery, food processing, water and wastewater treatment, mining, and packaging systems.
