Technical Specifications
| Item | Specification |
|---|---|
| Product Model | TCSEGDB23F24FA |
| Product Type | Proxy Module |
| Communication Ports | 2 x Modbus TCP Ethernet ports |
| Supported Protocols | Modbus TCP, Modbus RTU |
| Power Supply Voltage | 24 V DC (range: 19.2 to 30 V) |
| Power Consumption | Max. 3.2 W |
| Baud Rate | 10/100 Mbps auto-sensing |
| Mounting Type | 35 mm DIN rail mounting |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Vibration Resistance | 1.5 mm @ 10–55 Hz, 2 hours |
| Shock Resistance | 15 g for 11 ms |
| Certifications | CE, UL, CSA, RoHS |
| Dimensions | Package size: 60 x 180 x 260mm |
| Weight | Package weight 0.69kg |
FAQ
FAQ
Q1: What is the function of the TCSEGDB23F24FA module?
It acts as a proxy to convert Modbus TCP to Modbus RTU, enabling communication between Ethernet and serial devices.
Q2: Which protocols does it support?
It supports Modbus TCP and Modbus RTU.
Q3: Does it support redundant communication?
Yes, it has two Ethernet ports that can be configured for network redundancy.
Q4: How is the module powered?
It requires a 24 V DC external power supply.
Q5: Where can it be installed?
It can be installed on a standard 35 mm DIN rail, suitable for control cabinets.
Q6: Is hot swapping supported?
No, hot swapping is not supported. Power must be off during installation or replacement.
Q7: What is its maximum power consumption?
It consumes up to 3.2 watts.
Q8: What are the dimensions and weight of the module?
The dimensions are package size: 60 x 180 x 260mm and it package weight 0.69kg.
