Technical Specifications
| Item | Specification |
|---|---|
| Model | TCSESM083F23F0 |
| Product Type | Managed Industrial Ethernet Switch |
| Ethernet Ports | 8 × 10/100 Mbps RJ45 copper ports |
| Supported Protocols / Features | VLAN, IGMP Snooping, multicast filtering, QoS, RSTP, ring redundancy, data-stream control, Web configuration interface |
| Redundancy Support | Redundant power supply and ring topology redundancy (up to 50 switches in ring) |
| Power Supply | 9.6–60 V DC or 18–30 V AC SELV |
| Power Consumption | Approx. 5–6 W |
| Mounting | 35 mm DIN rail |
| Cabling | Shielded twisted-pair (CAT5E) with RJ45 connectors |
| Max Cable Distance (copper) | Up to 100 m per segment |
| Operating Temperature | 0–60 °C |
| Protection | IP20, suitable for industrial environments |
| Dimensions | 74 x 131 x 111 mm |
| Weight | 0.41 kg |
FAQ
FAQ
Q1: What type of environment is this switch intended for?
A1: Suitable for industrial automation networks, PLC/DCS systems, distributed I/O architectures requiring managed Ethernet and redundancy.
Q2: Does it support network redundancy and ring topology?
A2: Yes, it supports redundant power supply and up to 50 switches can form a ring for redundancy.
Q3: What management functions does it support?
A3: Supports VLAN, QoS, IGMP Snooping, multicast filtering, RSTP, and other features for network segmentation, priority handling, and stable operation.
Q4: What is the maximum copper cable length supported per segment?
A4: Up to 100 m per segment using CAT5E shielded twisted-pair copper cable.
Q5: Is installation complicated?
A5: No, it mounts on a standard 35 mm DIN rail, suitable for control cabinets.
Q6: Can it operate in industrial conditions?
A6: Yes, designed for industrial environments, operating temperature 0–60 °C, IP20 protection.
Q7: Does it require active maintenance or cooling?
A7: No, fanless low-power design; only routine inspection is needed.
Q8: What is the expected service life?
A8: Normally 8–10 years or longer under proper usage.
