Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric TM221C24U |
| Manufacturer | Schneider Electric |
| Product Series | Modicon M221 |
| Product Type | Compact Logic Controller / PLC |
| Integrated Digital I/O | 24 points |
| Digital Inputs | 14 inputs |
| Fast Inputs | 4 high-speed inputs |
| Analog Inputs | 2 inputs, 0–10 V |
| Digital Outputs | 10 transistor outputs |
| Output Type | NPN transistor / Sink |
| Output Voltage | 24 VDC |
| Output Current | 0.5 A per output |
| Supply Voltage | 24 VDC |
| Supply Voltage Range | 20.4–28.8 VDC |
| High-Speed Functions | HSC, PTO, PWM, PLS, Frequency Generator |
| Ethernet | Yes |
| Ethernet Port | RJ45 |
| Serial Communication | Serial Line, RS232/RS485 |
| USB | USB programming port |
| SD Card | Supported |
| Expansion Capability | Up to 7 TM3 expansion modules |
| Analog Input Resolution | 10 bit |
| Mounting | DIN rail / panel mounting |
| Protection Rating | IP20 |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions | 110 × 90 × 70 mm (W × H × D) |
| Product Weight | Approx. 0.395 kg |
FAQ
FAQ
Q1: What is the Schneider Electric TM221C24U used for?
A: The TM221C24U is a Modicon M221 PLC designed for machine automation applications such as packaging equipment, conveyors, assembly machines, material handling systems and OEM machinery.
Q2: How many I/O points does the TM221C24U have?
A: It has 24 integrated I/O points, including 14 digital inputs and 10 transistor outputs.
Q3: What type of outputs does the TM221C24U use?
A: It uses 10 NPN transistor outputs, also known as sink outputs, with a rated output current of 0.5 A per channel.
Q4: What power supply does the TM221C24U require?
A: The controller requires a 24 VDC power supply, with an allowable supply range of 20.4–28.8 VDC.
Q5: Does the TM221C24U have analog inputs?
A: Yes. It provides 2 analog inputs, supporting 0–10 V signals with 10-bit resolution.
Q6: Does the TM221C24U support Ethernet communication?
A: Yes. The controller includes an RJ45 Ethernet port, along with serial communication and USB programming interfaces.
Q7: Is the TM221C24U still available?
A: The model has been discontinued in several markets. Schneider Electric lists TM221C24T as a recommended replacement in some regions.
Q8: What are the dimensions and weight of the TM221C24U?
A: The controller measures approximately 110 × 90 × 70 mm (W × H × D), with a product weight of approximately 0.395 kg.
