Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | Schneider Electric TM221ME16TG |
| Manufacturer | Schneider Electric |
| Product Series | Modicon M221 |
| Product Type | Compact Logic Controller / PLC |
| Integrated I/O | 16 points |
| Digital Inputs | 8 |
| Analog Inputs | 2 |
| Digital Outputs | 8 transistor outputs |
| Output Type | PNP transistor / Source output |
| Fast Inputs | 4 |
| Fast Outputs | 2 |
| Output Voltage | 24 VDC |
| Output Current | 0.5 A per output |
| Supply Voltage | 24 VDC |
| Supply Voltage Range | 20.4–28.8 VDC |
| High-Speed Functions | HSC, PTO, PWM, PLS, Frequency Generator |
| Motion Functions | Pulse/Direction, A/B, Single Phase |
| Ethernet | Yes |
| Ethernet Port | RJ45, 10/100 Mbps |
| Serial Communication | RS232/RS485 |
| USB Interface | Mini-B USB 2.0 |
| SD Card | Supported |
| Communication Protocols | Modbus TCP, Modbus RTU/ASCII |
| Application Memory | 256 kB |
| Expansion | Modicon TM3 expansion modules |
| Terminal Type | Spring terminal |
| Programming Software | EcoStruxure Machine Expert / Machine Expert Basic |
| Mounting | DIN rail / panel mounting |
| Protection Rating | IP20 |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Dimensions | 70 × 90 × 70 mm (W × H × D) |
| Product Weight | Approx. 0.264 kg |
FAQ
FAQ
Q1: What is the Schneider Electric TM221ME16TG used for?
A: The TM221ME16TG is a compact Modicon M221 PLC for machine automation, packaging equipment, conveyors, assembly machines and OEM applications.
Q2: How many I/O points does the TM221ME16TG have?
A: It provides 16 integrated I/O points, consisting of 8 digital inputs and 8 PNP transistor outputs, plus 2 analog inputs.
Q3: What type of outputs does the TM221ME16TG use?
A: It uses PNP transistor/source outputs, making it suitable for fast switching and pulse-control applications.
Q4: What power supply does the TM221ME16TG require?
A: The controller is designed for a 24 VDC power supply.
Q5: Does the TM221ME16TG support analog inputs?
A: Yes. It includes 2 analog inputs for analog signal acquisition.
Q6: Does the TM221ME16TG support Ethernet communication?
A: Yes. It has an Ethernet port as well as a serial communication interface.
Q7: What is the difference between TM221ME16T and TM221ME16TG?
A: Both are 16-I/O M221 PLCs with PNP transistor outputs and Ethernet. The key difference is the terminal connection: TM221ME16TG uses spring terminals.
Q8: What are the dimensions and weight of the TM221ME16TG?
A: The controller has a compact M221 Book-format design. The dimensions are approximately 70 × 90 × 70 mm (W × H × D), with a product weight of approximately 0.264 kg.
