Technical Specifications
| Item | Specification |
|---|---|
| Model | TM258LF42DT |
| Series | Modicon M258 |
| Total I/O Points | 42 (Digital I/O) |
| Digital Inputs | 16 DI |
| Digital Outputs | 12 DO + 4 Fast Outputs |
| Input Voltage | 24 V DC (“1” ≥ 15 V, “0” ≤ 5 V) |
| Output Voltage | 24 V DC (source type output) |
| Power Supply | 24 V DC, range 20.4–28.8 V DC |
| Memory | 128 MB Flash + 64 MB RAM |
| Isolation | 500 Vrms between channels and logic |
| Communication Interfaces | Ethernet, CANopen, USB, Serial (RS‑232/RS‑485) |
| CPU Execution Speed | Approx. 22 ns per boolean instruction |
| Mounting | DIN rail |
| Protection Rating | IP20 |
| Dimensions | 175 x 99 x 85 mm |
| Weight | 0.55 kg |
FAQ
FAQ
Q1: How many I/O points does TM258LF42DT support?
A1: A total of 42 digital I/O points.
Q2: What is the configuration of digital inputs and outputs?
A2: 16 digital inputs, 12 standard outputs, and 4 fast outputs.
Q3: What is the input and output voltage range?
A3: Inputs are 24 V DC (“1” ≥ 15 V, “0” ≤ 5 V); outputs are 24 V DC, source type.
Q4: What power supply does the controller require?
A4: 24 V DC, range 20.4–28.8 V DC.
Q5: What is the memory and CPU performance?
A5: 128 MB Flash and 64 MB RAM, CPU executes boolean instructions in approx. 22 ns.
Q6: What communication interfaces are supported?
A6: Ethernet, CANopen, USB programming port, and Serial (RS‑232/RS‑485).
Q7: What are the dimensions and weight of the controller?
A7: Dimensions: 175 x 99 x 85 mm; Weight: 0.55 kg.
Q8: What are the operating and storage temperature ranges?
A8: Operating: 0–55 °C; Storage: –25–70 °C.
