Technical Specifications
| Item | Specification |
|---|---|
| Model | TM2DDI16DT |
| Product Name | Discrete Input Module |
| Manufacturer | Schneider Electric |
| Series | Modicon TM2 |
| Product Type | Digital input module |
| Number of Inputs | 16 channels |
| Input Type | Discrete |
| Input Voltage | 24 V DC |
| Input Logic | Negative logic (sinking) |
| Electrical Isolation | Channel-to-backplane isolation |
| Input Filtering | Integrated digital filter |
| Response Time | High-speed input processing |
| Max Input Current | Low-power input design |
| Status Indication | LED per channel |
| Diagnostic Function | Signal failure detection |
| Wiring Type | Spring terminal |
| Mounting | TM2 system rack |
| Protection Function | Overvoltage and polarity protection |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| EMC Compliance | Industrial EMC standards |
| Dimensions (L × W × H) | 94.6 x 90 x 27.3 mm |
| Weight | 0.065 kg |
FAQ
FAQ
Q1: What is the difference between this module and a positive logic input module?
A1: This model uses negative logic, meaning current flows from the module input to the field device, suitable for sinking-type outputs.
Q2: Can the input channels accept high-frequency signals?
A2: It supports fast signal detection, but extremely high-frequency signals should be tested against the digital filter settings.
Q3: How are wiring errors indicated?
A3: Incorrect wiring typically results in no LED indication, and the PLC software will report missing or inactive signals.
Q4: Is software configuration mandatory for operation?
A4: Yes, the module must be configured in the PLC project before the channels become active.
Q5: Does the module provide protection against wiring faults?
A5: It includes protection against overvoltage and reverse polarity to reduce damage risk.
Q6: Are the LEDs configurable through software?
A6: No, the LEDs operate automatically and directly reflect the electrical state of each input.
Q7: Can this module be mixed with other TM2 I/O modules in the same rack?
A7: Yes, it is fully compatible with other TM2 series I/O modules.
Q8: What should be checked if several inputs stop working at the same time?
A8: Verify field power supply, terminal connections, and the backplane connection to the controller.
