Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider TM3AI8 |
| Type | Analog Input Module |
| Number of Channels | 8 analog inputs |
| Input Types | Current (4–20 mA) / Voltage (0–10 V) |
| Resolution | 12-bit |
| Accuracy | ±0.2% of full scale |
| Input Impedance | Voltage ≥ 200 kΩ; Current ≥ 250 Ω |
| Isolation | Channel-to-bus isolation |
| Operating Voltage | 24 VDC (from main PLC) |
| Power Consumption | ≤ 2.5 W |
| Operating Temperature | 0 ~ 55°C |
| Storage Temperature | –25 ~ 70°C |
| Dimensions | 90 x 70 x 23.6 mm |
| Weight | 0.11 kg |
FAQ
FAQ
Q1: What input signal types does the TM3AI8 support?
A1: It supports 4–20 mA current inputs and 0–10 V voltage inputs.
Q2: How many input channels does the module provide?
A2: It provides 8 analog input channels.
Q3: Is it compatible with the TM200 PLC series?
A3: Yes, it is compatible with both TM200 and TM300 PLC series.
Q4: Does the module include electrical isolation?
A4: Yes, it provides channel-to-bus electrical isolation.
Q5: Does the TM3AI8 require an external power supply?
A5: No, it is powered by the main PLC (24 VDC).
Q6: What types of sensors can be connected?
A6: Any 4–20 mA or 0–10 V transmitter such as pressure, temperature, level, or flow sensors.
Q7: What is the resolution of the module?
A7: The module features a 12-bit resolution.
Q8: What are the dimensions and weight of the module?
A8: Dimensions are 90 x 70 x 23.6 mm, and weight is 0.11 kg.
