Technical Specifications
| Item | Specification |
|---|---|
| Model Number | TM3DM24RG |
| Brand | Schneider Electric |
| Product Type | Discrete I/O Expansion Module |
| Number of Inputs | 12 discrete inputs (24 VDC sink/source) |
| Number of Outputs | 12 transistor outputs (sink type) |
| Input Voltage | 24 VDC |
| Output Voltage | 24 VDC nominal |
| Max Output Current | 0.5 A per channel, 4 A total (per common) |
| Output Type | Transistor (short-circuit protected) |
| Isolation | Yes, between I/O and logic |
| Response Time | ≤ 1 ms typical |
| Diagnostics | Channel status and short-circuit detection |
| Operating Temp | 0°C to +55°C |
| Storage Temp | -40°C to +85°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Mounting Method | DIN rail mounting |
| Material | Industrial-grade plastic housing |
| Dimensions | 90 x 84.6 x 42.9mm |
| Weight | Package weight 0.27kg |
FAQ
FAQ
Q1: What is the function of the TM3DM24RG module?
It expands discrete I/O capacity with 12 digital inputs and 12 transistor (sink) outputs for fast switching applications.
Q2: How does the TM3DM24RG differ from the TM3DM24R?
The TM3DM24RG uses transistor outputs (sinking type), while the TM3DM24R uses relay outputs.
Q3: Is this module compatible with Schneider Modicon PLCs?
Yes, it is compatible with Modicon M221, M241, and M251 PLCs via the TM3 bus.
Q4: What type of outputs are used in this module?
The outputs are sinking-type transistors, suitable for high-speed DC loads.
Q5: Are the outputs protected against short circuits?
Yes, the module features integrated short-circuit protection on the output channels.
Q6: What is the response time of the outputs?
The typical switching response time is less than 1 ms, ideal for time-sensitive applications.
Q7: What is the maximum current per output channel?
Each output channel supports up to 0.5 A, with a shared total of 4 A per output common.
Q8: Can this module be DIN rail mounted?
Yes, it is designed for easy DIN rail installation within standard control cabinets.
