Technical Specifications
| Item | Specification |
|---|---|
| Model | TM3DQ8T |
| Product Name | Discrete Output Module |
| Manufacturer | Schneider Electric |
| Series | Modicon TM3 |
| Product Type | Digital output module |
| Number of Outputs | 8 channels |
| Output Type | Transistor / Discrete |
| Output Voltage | 24 V DC |
| Max Output Current | 0.5 A per channel |
| Electrical Isolation | Channel-to-backplane isolation |
| Status Indication | LED indicator for each output |
| Diagnostic Features | Short-circuit and load monitoring |
| Output Configuration | Sink/source configurable |
| Wiring Type | Spring terminal |
| Mounting Method | TM3 rack mounting |
| Protection Functions | Overvoltage, short-circuit protection |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| EMC Compliance | Industrial EMC standards |
| Dimensions (L × W × H) | 90 x 84.6 x 27.4 mm |
| Weight | 0.76 kg |
FAQ
FAQ
Q1: What types of devices can be controlled with the TM3DQ8T?
A1: It can control low-voltage DC devices such as solenoids, relays, and signal lamps.
Q2: How is the status of each output indicated?
A2: Each channel has an LED that shows whether the output is active or inactive.
Q3: Does the module offer protection against short circuits?
A3: Yes, all channels include built-in short-circuit protection.
Q4: Can the outputs be wired as sink or source?
A4: Yes, each output is configurable to sink or source to match system requirements.
Q5: Is the module suitable for industrial environments?
A5: Yes, it complies with industrial EMC standards for operation in electrically noisy environments.
Q6: How does the module report abnormal conditions?
A6: Overloads and short-circuit conditions are communicated to the connected PLC for diagnostics.
Q7: What is the recommended operating temperature range?
A7: The module is designed to operate between -20°C and +60°C.
Q8: What type of terminal connection does this module use?
A8: The TM3DQ8T uses spring terminals for secure and easy wiring.
