Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider TSX SCP 114 |
| Type | Communication Processor Module |
| Product Category | PLC communication module |
| Product Family | Modicon Premium automation platform |
| Communication Network | FIPIO fieldbus |
| Function | High-speed data exchange between PLC and distributed devices |
| Transmission Method | Deterministic fieldbus communication |
| Data Transfer Rate | Up to 1 Mbps (FIPIO standard) |
| Addressing Capacity | Supports multiple remote stations on FIPIO network |
| Mounting Method | Rack-mounted module |
| Slot Requirement | One standard Modicon Premium rack slot |
| Electrical Connection | Front-panel fieldbus connector |
| Isolation | Galvanic isolation between bus and internal logic |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –20 °C to +70 °C |
| Housing Material | Industrial-grade plastic with metal shielding |
| Application Environment | Industrial automation and control cabinets |
| Compatibility | Modicon Premium CPUs and FIPIO-compatible devices |
| Dimensions | Approx. 130 mm × 30 mm × 120 mm |
| Weight | Approximately 0.35 kg |
FAQ
FAQ
Q1: What is the primary function of the TSX SCP 114 module?
It enables communication between a Modicon Premium PLC and distributed devices over a FIPIO fieldbus network.
Q2: Which communication protocol does the TSX SCP 114 use?
The module operates on the FIPIO fieldbus protocol, designed for deterministic industrial communication.
Q3: What types of devices can be connected using this module?
It can communicate with remote I/O stations, drives, and other automation devices that support FIPIO communication.
Q4: Does the TSX SCP 114 require a dedicated power supply?
No, it is powered directly through the Modicon Premium rack backplane.
Q5: Can the TSX SCP 114 be installed in any rack slot?
Yes, it is designed to fit into a standard Modicon Premium rack slot.
Q6: Is the module suitable for continuous industrial operation?
Yes, it is designed for continuous operation in industrial environments within the specified temperature range.
Q7: How is the TSX SCP 114 configured?
Configuration is performed through the PLC programming software as part of the Modicon Premium system setup.
Q8: What are the physical dimensions and weight of the TSX SCP 114?
The module measures approximately 130 mm × 30 mm × 120 mm and weighs about 0.35 kg.
