Schneider TSXP57104M Unity processor

Frequently Asked Questions (FAQs)

Q1: What is the maximum number of I/O modules supported by the TSXP57104M processor?
A1: The processor supports up to 512 discrete I/O points and 24 analog I/O points.

Q2: Does the TSXP57104M support PCMCIA memory expansion?
A2: Yes, it supports a PCMCIA card with up to 256 kB additional data storage.

Q3: What communication interface is integrated in this processor?
A3: It includes a non-isolated serial link with 2 female mini DIN RS485 connectors operating at 19.2 kbit/s.

Q4: What is the total memory available without using a PCMCIA card?
A4: Without a PCMCIA card, the processor provides 96 kB of combined program and data memory.

Q5: How does the execution speed vary with and without a PCMCIA card?
A5: Boolean instructions execute at 0.19 µs without a card and 0.25 µs with a card. Floating-point instructions take 1.75 to 2.6 µs in both cases.

Q6: What are the operating temperature limits of the TSXP57104M?
A6: The processor operates reliably within a temperature range of 0°C to 60°C (32°F to 140°F).

Q7: What type of local LED indicators are available on the unit?
A7: The unit provides LEDs for processor run (green), I/O or configuration fault (red), system fault (red), and terminal activity (yellow).

Q8: What certifications does the TSXP57104M comply with for marine and industrial applications?
A8: It holds certifications from ABS, BV, DNV, GL, LR, RINA, and RMRS, suitable for demanding industrial and marine environments.

Schneider TSXP57104M Unity processor

We will use wear-resistant cartons to seal the boxes, and take photos for your confirmation before sealing. We will pack the boxes only after confirmation.

For express delivery, we will use DHL, UPS, TNT, FedEx and EMS.

Please rest assured that we have a deep cooperation with express delivery companies and can ensure that your goods are delivered to you in good condition.
