Technical Specifications
| Parameter | Specification |
|---|---|
| Model | TSXP573634M |
| Type | Unity Processor |
| CPU Type | Multi-tasking |
| Communication Interfaces | Modbus, Ethernet, CANopen |
| Power Supply | 24 V DC |
| Power Consumption | 12 W (typical) |
| Memory Capacity | Program 1 MB, Data 512 KB |
| I/O Support | Supports digital, analog, and high-speed counter modules |
| Operating Temperature | 0 ~ 60 °C |
| Storage Temperature | -20 ~ 70 °C |
| Relative Humidity | 5% ~ 95% (non-condensing) |
| Dimensions | 95 x 180 x 260 mm |
| Weight | 0.757 kg |
| Protection Rating | IP20 |
FAQ
FAQ
QA1: Which programming languages does TSXP573634M support?
Supports Unity Pro / EcoStruxure Control Expert, including Ladder Diagram (LD), Function Block Diagram (FBD), Structured Text (ST), etc.
QA2: What is the maximum program memory?
Maximum program memory is 1 MB.
QA3: Which communication interfaces can be used for remote monitoring?
Remote monitoring and data acquisition are possible via Modbus, Ethernet, or CANopen interfaces.
QA4: What is the operating temperature range?
Operating temperature range is 0 ~ 60 °C.
QA5: What types of I/O modules are supported?
Supports digital, analog, and high-speed counter modules.
QA6: What are the power requirements?
Requires 24 V DC power supply, typical consumption is 12 W.
QA7: What are the dimensions and weight?
Dimensions are 95 x 180 x 260 mm, weight is 0.757 kg.
QA8: What is the protection rating?
Protection rating is IP20, suitable for installation inside control cabinets.
