Technical Specifications
| Parameter | Description |
|---|---|
| Model | TSXP5Y5500M |
| Type | Power Module |
| Function | Provides stable DC power to Schneider Modicon TSX PLC series, ensuring proper operation of the controller and expansion modules |
| Output Voltage | 24 V DC |
| Output Current | 5 A |
| Input Voltage | 100 – 240 V AC / 120 – 300 V DC |
| Efficiency | High-efficiency regulated output, low power consumption |
| Mounting | DIN rail mounting |
| Status Indicator | On-board LED indicating power status |
| Dimensions | 95 x 180 x 260 mm |
| Weight | 0.971 kg |
| Operating Temperature | 0°C – 60°C |
| Storage Temperature | –20°C – 85°C |
FAQ
FAQ
Q1: What is the purpose of TSXP5Y5500M?
A1: Provides stable DC power to Modicon TSX PLC series, ensuring proper operation of the controller and expansion modules.
Q2: What are the output voltage and current?
A2: 24 V DC output voltage, 5 A output current.
Q3: What is the input voltage range?
A3: 100 – 240 V AC or 120 – 300 V DC.
Q4: How is it mounted?
A4: DIN rail mounting.
Q5: Does it have a status indicator?
A5: Yes, an on-board LED indicates power status.
Q6: What are the dimensions and weight?
A6: 95 mm x 180 mm x 260 mm; weight is 0.971 kg.
Q7: What are the operating environmental conditions?
A7: Operating temperature 0°C – 60°C, storage –20°C – 85°C, humidity 5% – 95% non-condensing.
Q8: Can it be used independently?
A8: No, it must be used with Modicon TSX PLC controllers and expansion modules.
