Technical Specifications
| Item | Specification |
|---|---|
| Product Model | Woodward 5466-425D |
| Product Type | Analog Input/Output Module |
| Input Channels | 24 analog input channels |
| Output Channels | 8 analog output channels |
| Input Signal Type | 0–5 VDC |
| Output Signal Type | 4–20 mA current output |
| Resolution | 12-bit or higher |
| Accuracy | ±0.1% of full scale |
| Isolation Voltage | 1500 VDC between channel and system bus |
| Response Time | < 5 ms |
| Filtering | Low-latency filtering on channels 23 and 24 |
| Power Supply | 24 VDC (from backplane) |
| Power Consumption | 6 W typical |
| Indicators | Channel and power status LEDs |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack or backplane slot installation |
| System Compatibility | Woodward control systems (e.g., MicroNet series) |
| Dimensions | 180 × 120 × 25 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What is the main function of the Woodward 5466-425D module?
A1: It is used to acquire analog input signals and provide analog output control in industrial automation and process systems.
Q2: How many input and output channels does the module have?
A2: It provides 24 analog input channels and 8 analog output channels.
Q3: What types of signals does the module support?
A3: The input signals are 0–5 VDC, and the output signals are 4–20 mA current signals.
Q4: What are the accuracy and resolution of the module?
A4: The accuracy is ±0.1% of full scale with 12-bit or higher resolution.
Q5: How is the module electrically isolated?
A5: Each channel is isolated from the system bus by 1500 VDC for signal integrity and safety.
Q6: What is the response time of the module?
A6: The response time is less than 5 milliseconds.
Q7: What are the module’s dimensions and weight?
A7: Dimensions are 180 × 120 × 25 mm, and weight is 0.6 kg.
Q8: Which systems is the module compatible with?
A8: It is compatible with Woodward MicroNet and similar control systems.
Tags
