Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Woodward |
| Model | SPM-D2-1040B/NYB |
| Part Number | 8440-2189 |
| Product Type | Microprocessor-Based Synchronizer |
| Product Series | SPM-D2-10 |
| Application | 3-Phase Paralleling |
| Main Function | Generator synchronization and circuit-breaker control |
| Voltage Matching | Yes |
| Frequency Matching | Yes |
| Phase Matching | Yes |
| Synchronizing Mode | Automatic synchronizing |
| Generator Application | Three-phase generator systems |
| Typical Use | Generator sets, power generation and industrial turbine systems |
| Control Function | Generator breaker / bus breaker control |
| Status Indication | LED indicators for voltage, frequency and breaker status |
| Documentation | Product Specification 37622 / Manual 37617 |
| Mounting | Panel mounting |
| Weight | Approx. 2.0 kg |
| Dimensions (L × W × H) | Approx. 216 × 160 × 55 mm |
FAQ
FAQ
Q1: What is the Woodward 8440-2189 used for?
A: The 8440-2189 is a Woodward SPM-D2-1040B/NYB synchronizer designed for three-phase generator paralleling applications.
Q2: What type of device is the 8440-2189?
A: It is a microprocessor-based synchronizer in the Woodward SPM-D2-10 series. Its main role is to synchronize a generator with a bus before closing the generator circuit breaker.
Q3: Does the SPM-D2-1040B/NYB support three-phase paralleling?
A: Yes. Woodward lists the SPM-D2-1040B/NYB (8440-2189) specifically in its three-phase paralleling product group.
Q4: What parameters does the 8440-2189 monitor during synchronization?
A: The synchronizer compares generator and bus electrical conditions, including voltage, frequency and phase relationship, and provides control signals to achieve synchronization.
Q5: Can the 8440-2189 control the generator circuit breaker?
A: Yes. The SPM-D2-10 synchronizer is intended to provide the control necessary for generator-to-bus synchronization and breaker closing in paralleling applications. Product information also identifies generator and bus circuit-breaker status indications.
Q6: What documentation is available for the 8440-2189?
A: Woodward identifies Product Specification 37622 and Manual 37617 for the SPM-D2-1040B/NYB configuration.
Q7: Is the 8440-2189 suitable for industrial power-generation applications?
A: Yes. The SPM-D2 series is used in generator paralleling and industrial power-generation applications where controlled synchronization is required.
Q8: What are the dimensions and weight of the Woodward 8440-2189?
A: The commonly referenced weight is approximately 2.0 kg, with approximate dimensions of 216 × 160 × 55 mm. Exact dimensions can depend on the mounting and enclosure configuration, so the original Woodward mechanical drawing should be used for precise cabinet or shipping calculations.
