Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 9905-007N |
| Series | Woodward 9905 |
| Type | Digital Synchronizer and Load Control |
| Control Type | Microprocessor-Based Digital Control |
| Synchronization Type | Generator to Bus Synchronization |
| Load Control | Automatic load sharing and shedding |
| Voltage Range | 0–600 VAC |
| Frequency Range | 45–65 Hz |
| Phase Sequence | ABC or custom configuration |
| Input Power Supply | 24 VDC nominal |
| Communication | Modbus RTU, RS-485 |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Protection Features | Overvoltage, undervoltage, over/under frequency, phase loss, reverse power |
| Display | LED indicators for phase, voltage, load, and synchronization status |
| Mounting Type | Panel or cabinet mount |
| Diagnostics | Event logging, fault history, and alarm monitoring |
| Features | Automatic and manual synchronization, adjustable synchronizing thresholds, load control, parallel operation support |
| Dimensions | 191 x 30 x 240 mm |
| Shipping Weight | 1.8 kg |
FAQ
FAQ
Q1: What is the primary function of the Woodward 9905-007N?
A1: It provides automatic generator synchronization and load control, ensuring safe parallel operation and optimal load distribution.
Q2: Which voltage and frequency ranges does this device support?
A2: The device operates within 0–600 VAC and 45–65 Hz frequency range.
Q3: Can the 9905-007N handle different phase sequences?
A3: Yes, it supports standard ABC phase sequence and can be configured for custom phase sequences.
Q4: What types of protection features are included?
A4: It includes protection for overvoltage, undervoltage, over/under frequency, phase loss, and reverse power conditions.
Q5: Does it support load sharing between multiple generators?
A5: Yes, it provides automatic load sharing and load shedding for multi-generator systems.
Q6: Is automatic synchronization supported?
A6: Yes, it supports both automatic and manual synchronization with adjustable thresholds.
Q7: What diagnostic capabilities does the 9905-007N offer?
A7: It includes event logging, fault history, alarm monitoring, and LED indicators for real-time operational status.
Q8: How is the 9905-007N installed in a control system?
A8: It is panel- or cabinet-mounted, providing secure installation with easy access to control interfaces and indicators.
