Technical Specifications
| Item | Specification |
|---|---|
| Model | Woodward 9905‑976 ProTech 203 |
| Type | Overspeed Protection System |
| Input Voltage | 120 Vac / 120 Vdc (acceptable range 88–132 Vac / 90–150 Vdc) |
| Power Consumption | Approx. 7.25 W |
| Speed Sensor Inputs | Triple magnetic pick-ups (MPU) |
| Overspeed Logic | Hardware two‑out‑of‑three voting |
| Trip Response Time | Up to 40 ms |
| Trip Mechanism | De‑energize to trip when overspeed detected |
| User Interface | 12-key keypad + display |
| Trip Speed Set Point | 250 rpm to 25,000 rpm, configurable |
| MPU-Fail Set Point | 100 rpm to 25,000 rpm, configurable |
| Operating Temperature | –25°C to +60°C |
| Dimensions | 120 × 100 × 50 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: What is the main function of the 9905‑976 module?
A1: Monitors rotating machinery speed, detects overspeed conditions, and triggers trips to protect equipment.
Q2: Why use three sensors and a 2/3 voting logic?
A2: Enhances system safety; only when two sensors detect overspeed does it trip, reducing false trips.
Q3: What type of speed sensors are supported?
A3: Magnetic pick-ups (MPU).
Q4: What is the trip response time?
A4: Up to 40 milliseconds.
Q5: Does the trip mechanism de-energize the system?
A5: Yes, it cuts power when overspeed is detected.
Q6: Can the module be configured on-site?
A6: Yes, it has a 12-key keypad and display for local configuration.
Q7: What is the operating temperature range?
A7: –25°C to +60°C.
Q8: Is it suitable for critical safety applications?
A8: Yes, it is a high-reliability, redundant protection system for critical rotating equipment.
