Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Analog Output Module |
| Model Number | AAI543-H00 S1 |
| Number of Channels | 8 channels |
| Output Type | Current output (0–20 mA / 4–20 mA) |
| Resolution | 16 bits |
| Accuracy | ±0.1% of span |
| Load Resistance | ≤ 750 Ω |
| Isolation | Channel-to-channel and channel-to-ground |
| Power Supply | Supplied via FIO base unit |
| Diagnostics | Self-diagnostics and fault detection |
| Mounting Type | DIN rail |
| Hot Swap | Supported |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -20 to +70 °C |
| Relative Humidity | 5% to 95%, non-condensing |
FAQ
FAQ
Q1: How many output channels does the AAI543-H00 S1 module provide?
A1: It provides 8 analog output channels.
Q2: What output signal types does the module support?
A2: The module supports current output signals of 0–20 mA and 4–20 mA.
Q3: What is the resolution of the analog output?
A3: The output resolution is 16 bits.
Q4: Does the module provide electrical isolation?
A4: Yes, channels are isolated from each other and from ground.
Q5: What is the maximum load resistance supported?
A5: The maximum load resistance supported is 750 ohms.
Q6: Does the module support hot swapping?
A6: Yes, the module supports hot swapping without shutting down the system.
Q7: How is the module powered?
A7: Power is supplied through the FIO system base unit.
Q8: What diagnostics features are available?
A8: The module includes self-diagnostics and fault detection functions.
