Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Yokogawa AAI543-S50/A4S00 |
| Type | Analog Output Module (Current Output, Isolated) |
| Number of Output Channels | 16, isolated |
| Output Signal | 4 to 20 mA |
| Withstanding Voltage | Between output and system: 1500 V AC for 1 minute |
| Allowable Load Resistance | 0 to 750 Ω |
| Circuit-open Detection | Less than 0.65 mA |
| Accuracy | ±48 µA |
| Data Update Period | 10 ms |
| Temperature Drift | ±16 µA / 10 °C |
| Maximum Current Consumption | 230 mA (5 V DC), 540 mA (24 V DC) |
| External Connection | Pressure clamp terminal |
| HART Communication | Available |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.4 kg |
FAQ
FAQ
Q1: What is the output type of the AAI543-S50/A4S00 module?
A1: It provides isolated 4 to 20 mA analog current outputs.
Q2: How many output channels does this module support?
A2: It supports 16 isolated output channels.
Q3: What is the allowable load resistance for this module?
A3: The allowable load resistance is 0 to 750 Ω.
Q4: Does the module support HART communication?
A4: Yes, it supports HART communication.
Q5: What is the module’s output accuracy?
A5: The output accuracy is ±48 µA.
Q6: What is the switch-over capability in redundant configurations?
A6: It supports standard switch-over response in redundant configurations.
Q7: What is the maximum current consumption?
A7: The maximum current consumption is 230 mA (5 V DC) and 540 mA (24 V DC).
Q8: What are the physical dimensions and weight?
A8: The dimensions are 107.5 × 32.8 × 130 mm and the weight is 0.4 kg.
