Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAI841-H50/K4A00 |
| Input Points | 8 points |
| Output Points | 4 points |
| Signal Type | Voltage/Current (jumper selectable) |
| Input Accuracy | ±0.1% (V)/±0.2% (A) |
| Output Accuracy | ±0.1% |
| Power Supply | 5V DC (via base unit) |
| Dimensions | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
| Operating Temp | -20~70℃ |
FAQ
FAQ
-
Q: HART protocol supported?
-
A: No, dedicated HART module required.
-
-
Q: External resistor for current input?
-
A: No, built-in 250-ohm resistor.
-
-
Q: Mixed signal types on inputs?
-
A: No, group configuration only.
-
-
Q: External power supply needed?
-
A: No, powered via PROFIBUS base.
-
-
Q: Output load capacity?
-
A: Current: 500 ohm max, Voltage: >1 kohm recommended.
-
-
Q: How to install?
-
A: Must use with PROFIBUS-DP/V1 base unit.
-
-
Q: Calibration interval?
-
A: 1 year recommended, depends on environment.
-
-
Q: Direct thermocouple connection?
-
A: No, dedicated temperature module needed.
-
