Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAM51-S214 |
| Product Type | Current and Voltage Output Module |
| Output Type | Current (4–20 mA) / Voltage (0–10 V) |
| Channels | 4 channels |
| Accuracy | ±0.1% full scale |
| Response Time | ≤100 ms (typical) |
| Operating Temperature | 0°C to 55°C |
| Supply Voltage | 24 VDC |
| Interface Type | Module terminal interface |
| Communication Protocol | Compatible with YOKOGAWA CENTUM VP system |
| Dimensions | 130 × 27 × 130 mm |
| Weight | 0.113 kg |
FAQ
FAQ
Q1: What applications is the AAM51-S214 module suitable for?
A: Mainly used in industrial process control systems to convert controller or computer signals into standard current or voltage outputs for controlling field devices.
Q2: What output types does it support?
A: Supports 4–20 mA current output and 0–10 V voltage output.
Q3: How many channels does the module support?
A: Standard module provides 4 output channels.
Q4: What is the accuracy?
A: Accuracy is ±0.1% full scale, suitable for most process control applications.
Q5: What is the operating temperature range?
A: Can operate stably from 0°C to 55°C.
Q6: How is the module installed?
A: Installed via the CENTUM VP system module slot and connected to control signal lines via terminals.
Q7: What is the power requirement?
A: Requires 24 VDC power supply.
Q8: What are the dimensions and weight of the module?
A: Dimensions are 130 × 27 × 130 mm, weight approximately 0.113 kg.
