Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AAP149-S00 |
| Number of Input Channels | 16 channels, non-isolated |
| Input Signal Type | Transistor contact (open collector) |
| Pulse Detection Edge | Trailing edge |
| Input Frequency | 0 to 6 kHz |
| Minimum Pulse Width | 40 µs (typical) |
| Data Update Period | 2 ms |
| Withstanding Voltage | Not supported (non-isolated) |
| Max Current Consumption | 400 mA (5 V DC) |
| External Connection | Dedicated KS2 cable |
| Dimensions (W×D×H) | 127.2 x 32.8 x 130 mm |
| Weight | Approx. 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of input signal does the AAP149-S00 support?
A1: It supports pulse input from transistor contacts (open collector type).
Q2: Is the module electrically isolated?
A2: No, the AAP149-S00 is a non-isolated module.
Q3: What is the maximum input frequency supported?
A3: The module supports pulse inputs up to 6 kHz.
Q4: What is the minimum input pulse width?
A4: The minimum supported pulse width is 40 microseconds.
Q5: Does this module support redundant configuration?
A5: No, AAP149-S00 is designed for PM1 systems and does not support redundancy. Use AAP135 for redundant applications.
Q6: What is the data update rate?
A6: The data update period is 2 milliseconds.
Q7: What kind of external connection is used?
A7: The module connects via Yokogawa’s dedicated KS2 cable.
Q8: What are the physical dimensions and weight?
A8: Dimensions are 127.2 x 32.8 x 130 mm and the weight is approximately 0.3 kg.
