Technical Specifications
| Parameter | Description |
|---|---|
| Model | ADV551-P00/D5S00 |
| Type | Digital Output Module |
| Number of Channels | 32 channels |
| Output Type | Dry contact / Transistor output |
| Rated Voltage | 24 V DC |
| Rated Current | 0.5 A per channel |
| Isolation | Channel-to-bus isolation |
| Response Time | ≤ 1 ms |
| Power Consumption | 6 W |
| Operating Temperature | 0 to 55 ℃ |
| Storage Temperature | -20 to 70 ℃ |
| Dimensions | 107.5 × 130 × 32.8 mm |
| Weight | 0.2 kg |
| Installation | Slot mounting (I/O rack) |
| Typical Applications | Process control, sequence control, switching control |
FAQ
FAQ
-
Q1: How many output channels does the ADV551-P00/D5S00 provide?
A1: It provides 32 independent digital output channels. -
Q2: What is the maximum current per channel?
A2: Each channel can handle up to 0.5 A. -
Q3: What is the typical response time of the module?
A3: The response time is less than or equal to 1 ms, suitable for fast control. -
Q4: What is the rated operating voltage of the module?
A4: The rated voltage is 24 V DC. -
Q5: Does the module provide isolation between channels and the system bus?
A5: Yes, it features electrical isolation between output channels and the system bus. -
Q6: How is the module installed?
A6: It is installed via slot mounting on a Yokogawa I/O rack. -
Q7: What is the recommended operating temperature range?
A7: The module operates reliably within 0 to 55 ℃. -
Q8: What are the typical applications of this module?
A8: It is typically used in process automation, sequence control, and equipment switching control.
