Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Power Bus Unit |
| Model | AEPV7D-216 |
| Function | Distributes and supplies power to connected I/O modules |
| Input Voltage | 24 V DC (nominal) |
| Output Voltage | 24 V DC |
| Output Current Capacity | Up to 10 A total |
| Power Consumption | Approx. 5 W |
| Connector Type | Power bus connector for I/O module interconnection |
| Isolation | Electrical isolation between power and communication circuits |
| Protection | Overcurrent and reverse polarity protection |
| Indicators | Power ON indicator (LED) |
| Mounting | DIN rail or baseplate mounting |
| Dimensions | 630 × 166 × 43.6 mm |
| Weight | 2.9 kg |
| Operating Temperature | 0 to 55°C |
| Storage Temperature | -25 to 70°C |
| Cooling Method | Natural air circulation |
FAQ
FAQ
Q1: What is the function of the AEPV7D-216 Power Bus Unit?
The AEPV7D-216 distributes 24 V DC power to connected Yokogawa I/O modules, ensuring stable system operation.
Q2: What is the nominal input voltage?
The nominal input voltage is 24 V DC.
Q3: What is the maximum current capacity?
It supports a total output current of up to 10 A.
Q4: Does it include protection features?
Yes, it features overcurrent and reverse polarity protection to safeguard connected equipment.
Q5: How is the power bus connected to I/O modules?
It uses a power bus connector that allows direct interconnection with I/O modules.
Q6: Is there a status indicator?
Yes, a Power ON LED indicator shows when the unit is operating.
Q7: What are the dimensions and weight of the module?
The module measures 630 × 166 × 43.6 mm and weighs approximately 2.9 kg.
Q8: What is the operating temperature range?
The operating temperature range is from 0 to 55°C.
