Technical Specifications
| Item | Description |
|---|---|
| Product Model | Yokogawa AFS20D-H4221 |
| Product Type | Duplex Field Control Unit (FCU) |
| Manufacturer | Yokogawa Electric Corporation |
| Function | Provides redundant control capability, executes process control logic, and manages field I/O communication within distributed control systems |
| System Compatibility | CENTUM VP / CS 3000 |
| Processor Type | Dual 32-bit RISC processors (redundant configuration) |
| Memory Capacity | 32 MB main memory |
| Communication Interface | Dual Vnet/IP network ports |
| Supported Protocols | TCP/IP, UDP, SNTP |
| Power Supply Voltage | 24 V DC (dual redundant inputs supported) |
| Power Consumption | Approximately 40 W |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 5% to 95% RH (non-condensing) |
| Mounting Type | Mounted on system backplane |
| I/O Module Support | Supports analog, digital, and specialty I/O modules |
| Redundancy | CPU and power redundancy supported |
| Diagnostics | Built-in self-diagnosis and watchdog timer |
| Dimensions | 207 × 265.9 x 482.6 mm |
| Weight | 8.0 kg |
| Material | Aluminum and reinforced engineering plastic housing |
| Certifications | CE, UL, CSA, and RoHS compliant |
FAQ
FAQ
Q1: What is the main function of the Yokogawa AFS20D-H4221 Duplex Field Control Unit?
A1: The AFS20D-H4221 provides redundant process control and manages communication with field I/O devices in Yokogawa distributed control systems.
Q2: Which Yokogawa systems are compatible with this unit?
A2: It is compatible with CENTUM VP and CS 3000 control systems.
Q3: What type of redundancy does the AFS20D-H4221 support?
A3: It supports CPU and power redundancy to ensure continuous control operation without downtime.
Q4: What communication network does it use?
A4: The unit uses dual Vnet/IP communication ports for high-speed and reliable system communication.
Q5: What is the power requirement for this module?
A5: It operates on 24 V DC and supports dual redundant power supply inputs.
Q6: What environmental conditions can the AFS20D-H4221 operate in?
A6: It operates between 0°C and +55°C and in humidity levels from 5% to 95% (non-condensing).
Q7: Does the unit include diagnostic functions?
A7: Yes, it features built-in self-diagnostics and a watchdog timer for enhanced reliability.
Q8: What certifications does this product meet?
A8: It complies with CE, UL, CSA, and RoHS international standards.
