Technical Specifications
| Parameter | Description |
|---|---|
| Model | AFS30D |
| Type | Duplexed Field Control Unit |
| Mounting | 19-inch Rack Mountable |
| Network | V net (Yokogawa’s real-time control network) |
| Supported I/O | FIO (Fieldnetwork I/O) |
| Memory | 16 MB Main Memory |
| Control Functions | Control computation, input/output for process and software I/O |
| Communication Bus | ESB or ER Bus (for connecting I/O modules) |
| Transmission Speed | 128 Mbps (ESB/ER Bus) |
| Transmission Topology | Bus topology |
| Redundancy | Dual-redundant system support |
| Ambient Temperature | 0 – 50 °C |
| Ambient Humidity | 10 – 90 % RH (no condensation) |
| Power Supply | 100–120 V AC ±10%, 220–240 V AC ±10%, or 24 V DC ±10% |
| Withstanding Voltage | 1500 V AC (for AC input), 500 V AC (for DC input) |
| Insulation Resistance | 20 MΩ / 500 V DC |
| Installation Environment | Requires keyed metallic cabinet (for safety and EMC compliance) |
| Compliance | CE, CSA, FM, KC, Type n/Type i (Explosion-proof standards) |
| Dimensions | 207 × 265.9 × 482.6 mm |
| Weight | 8 kg |
FAQ
FAQ
Q1: What type of network communication does the AFS30D support?
A1: It supports Yokogawa’s V net, a real-time process control communication network.
Q2: Is redundancy supported by AFS30D?
A2: Yes, it features duplex (redundant) architecture for high availability and reliability.
Q3: What kind of I/O modules can be connected?
A3: It supports Fieldnetwork I/O (FIO) modules via ESB and ER communication buses.
Q4: How is the unit mounted?
A4: The AFS30D is designed for 19-inch rack mounting, suitable for industrial cabinets.
Q5: Can it operate in harsh industrial environments?
A5: Yes, it operates within 0 to 50°C and 10–90% RH with no condensation.
Q6: What international standards does it comply with?
A6: It complies with CE, CSA, FM, KC, and explosion protection standards (Type n, Type i).
Q7: What power supply options are available?
A7: It supports 100–120 V AC, 220–240 V AC, and 24 V DC input voltages.
Q8: What industries is the AFS30D suited for?
A8: It is ideal for oil and gas, petrochemical, power generation, water treatment, pharmaceutical, and food industries.
