Technical Specifications
| Parameter | Specification |
|---|---|
| Model | AIP830 |
| Product Type | Operation Keyboard for Single-loop Operation |
| Keyboard Type | Flat keyboard with USB sound function (USB speaker) |
| PC Interface | USB Type A ×2 (USB 2.0 for keyboard, USB 1.1 for sound) |
| Input Voltage | 5 V ±5% (Supplied via USB from PC) |
| Max Current Consumption | 1 A |
| Operating Temperature | 5 to 40°C (normal use), -20 to 60°C (storage/transport) |
| Operating Humidity | 20% to 80% RH (non-condensing) |
| Color | Black (equivalent to Munsell No. N1.5) |
| Weight | Approx. 2.5 kg (with VESA bracket) |
| Dimensions | 500 × 225 × 44 mm |
| Function Keys | 64 user-definable keys for process control and monitoring |
| Special Keys | Alarm acknowledgment, screen clear, mode switch (optional), built-in speaker |
| Certifications | CSA, CE, EAC, RCM, KC, Morocco Cم (when applicable to connected PC) |
| Installation Category | IEC 61010-1 Class I |
| VESA Mount Option | Yes (optional) |
| Cable Length | 2300 ±100 mm |
FAQ
FAQ
Q1: What is the primary use of the AIP830 keyboard?
A1: The AIP830 is used for single-loop operation in Yokogawa’s Desktop Type HIS systems, enabling precise plant process control.
Q2: Does the AIP830 include audio output functionality?
A2: Yes, it includes a built-in USB speaker that functions as an electronic buzzer for audio alerts.
Q3: Can the AIP830 keyboard operate independently?
A3: No, it must be connected to a Desktop Type HIS via USB and is powered directly from the PC.
Q4: What type of USB interfaces does it support?
A4: It supports USB 2.0 for keyboard functionality and USB 1.1 for sound functionality.
Q5: Is the AIP830 keyboard suitable for use in harsh environments?
A5: It supports temperatures from 5 to 40°C for normal operation and from -20 to 60°C for storage, but should be used in controlled indoor environments.
Q6: Can the AIP830 be mounted using a VESA bracket?
A6: Yes, the AIP830 has an optional VESA mounting bracket for secure installation.
Q7: What are the power requirements for this keyboard?
A7: It requires 5 V ±5% and up to 1 A, supplied via USB from the connected PC.
Q8: How many user-definable function keys does the AIP830 support?
A8: The AIP830 supports 64 user-definable function keys.
