Technical Specifications
| Item | Specification |
|---|---|
| Model | ALF111-S50 |
| Interface Type | FOUNDATION™ fieldbus (Low Speed Voltage Mode) |
| Communication Ports | 4 ports (1 segment per port) |
| Transmission Speed | 31.25 kbps |
| Communication Functions | Supports LAS and Clock Master functions |
| Control I/O Channels | Max. 48 points per segment (up to 6 high-speed scanned points) |
| Max Fieldbus Devices | Max. 32 devices per segment (including this module) |
| Redundancy Support | Supports dual-redundant configuration within the same node |
| Power Consumption | 0.5 A or less |
| Withstanding Voltage | 1500 V AC for 1 minute (channel to system, channel to channel) |
| Bus Connection | Removable pressure clamp terminal block with switchable terminators |
| Installation Units | Mountable on ANB10, ANB11, AFV30, AFV40, A2FV50, A2FV70 |
| Supported Control Functions | VP6F1700, VP6F1800, VP6F1900 |
| Dimensions | 130 mm × 125.5 mm × 32.8 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many fieldbus devices can ALF111-S50 support?
A1: It can support up to 32 devices per segment including the module itself.
Q2: Does the ALF111-S50 support redundancy?
A2: Yes. Dual-redundant configuration is supported by installing two modules in the same node.
Q3: What is the communication speed?
A3: The module communicates at 31.25 kbps.
Q4: How many I/O control channels are supported per segment?
A4: Each segment supports up to 48 control channels, with a maximum of 6 as high-speed scanning points.
Q5: Is a specific terminal required for installation?
A5: Yes, the AEF9D terminal board is recommended, and terminators (YCB138) must be used for unused ports.
Q6: What is the power consumption of the module?
A6: The current consumption is no more than 0.5 A.
Q7: Which FCS models are compatible with ALF111-S50?
A7: Compatible models include AFV30, AFV40, A2FV50, and A2FV70 series.
Q8: Is the module compliant with FOUNDATION fieldbus standards?
A8: Yes, it fully complies with FOUNDATION™ fieldbus H1 specifications.
