Technical Specifications Table
| Item | Specification |
|---|---|
| Model | ALP111 |
| Interface | PROFIBUS-DP |
| Connection Method | EIA-RS-485 compliant |
| Signal Isolation | Isolated |
| Transmission Speed | 9600 bps to 12 Mbps |
| Transmission Medium | Shielded Cable |
| Maximum Transmission Distance | 1.2 km (at 9600 bps transmission speed) |
| Number of Communication Ports | 1 port |
| Communication Port | D-sub 9 pin (female) |
| Maintenance Port | D-sub 9 pin (male), Interface: RS-232C |
| Maximum Current Consumption | 0.7 A |
| Weight | 0.3 kg |
| Dimensions | 130 x 129.5 x 32.8 mm |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum transmission speed of the ALP111 PROFIBUS-DP communication module?
A1: The maximum transmission speed of the ALP111 module is 12 Mbps.
Q2: What is the power consumption of the ALP111 module?
A2: The maximum current consumption of the ALP111 module is 0.7 A.
Q3: How many PROFIBUS slave devices can the ALP111 module support?
A3: The ALP111 module can support up to 31 PROFIBUS slave devices without repeaters and up to 125 slave devices with repeaters.
Q4: What type of maintenance port does the ALP111 module have?
A4: The ALP111 module has a D-sub 9 pin (male) maintenance port with an RS-232C interface.
Q5: What control stations are supported by the ALP111 module?
A5: The ALP111 module supports various control stations, including AFV30, AFV40, AFV10, etc.
Q6: Does the ALP111 module support redundant configuration?
A6: Yes, the ALP111 module supports redundant configuration by installing two ALP111 modules in adjacent slots to form a dual-redundant setup.
Q7: What is the maximum transmission distance for the ALP111 module?
A7: The maximum transmission distance for the ALP111 module is 1.2 km at 9600 bps transmission speed.
Q8: What are the external dimensions of the ALP111 module?
A8: The external dimensions of the ALP111 module are 130 x 129.5 x 32.8 mm.
