Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ANB10D-415/CU2N/NDEL |
| Function | ESB Bus Node Unit for CENTUM VP DCS |
| Power Supply | 100–120 V AC, 50/60 Hz |
| Power Consumption | 200 VA / 120 W |
| Redundancy | Dual-redundant power supply and ESB bus communication |
| Communication Protocol | ESB Bus |
| Mounting Method | 19-inch rack mount (M5 × 4 screws) |
| Operating Temperature | –20°C to +60°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Dimensions (W × H × D) | 482.6 × 221.5 × 205 mm |
| Weight | 10 kg |
| Suffix Codes | -4: Dual-redundant power supply -1: 100–120 V AC power supply -5: Basic type without explosion protection |
| Option Codes | /CU2N: Connector Unit for ESB Bus (2 pieces) /NDEL: Software License for Node Expansion |
FAQ
FAQ
-
Q1: What type of redundancy does the ANB10D-415/CU2N/NDEL support?
A1: It supports dual-redundant power supply and dual-redundant ESB bus communication to ensure continuous operation in case of component failure. -
Q2: What is the operating temperature range of this node unit?
A2: The unit operates reliably between –20°C and +60°C. -
Q3: How is the ANB10D-415/CU2N/NDEL mounted?
A3: It is mounted in a standard 19-inch rack using four M5 screws. -
Q4: Which communication modules are compatible with this ESB Bus Node Unit?
A4: Compatible modules include ALR111, ALR121, ALE111, ALF111, and ALP121. -
Q5: What is the function of the /NDEL option?
A5: The /NDEL option provides the software license for node expansion, enabling integration into the system. -
Q6: What are the physical dimensions and weight of the unit?
A6: The unit measures 482.6 × 221.5 × 205 mm and weighs 10 kg. -
Q7: What type of ESB Bus couplers can this unit interface with?
A7: It interfaces with EC401, EC402, A2EN402, A2EN404, and optical repeater modules ANT401 and ANT502. -
Q8: What is the power consumption and supply specification of this unit?
A8: The unit consumes 200 VA / 120 W and requires 100–120 V AC, 50/60 Hz power supply.
