Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Yokogawa Electric Corporation |
| Product Model | ANB11D-225 |
| Product Type | Optical ESB Bus Node Unit |
| Series | CENTUM VP / FIO System |
| Function | Provides dual-redundant optical ESB Bus communication between Field Control Units (FCUs) and FIO I/O nodes |
| Bus Type | Dual-Redundant Optical ESB Bus |
| Communication Interface | Optical ESB Bus |
| Redundancy | Dual-redundant architecture |
| Power Supply | 220–240 VAC (suffix dependent) |
| Power Supply Configuration | Dual-redundant |
| Optical Repeater Support | Supports 5 km optical repeater configuration |
| Mounting Type | 19-inch Rack Mount |
| Compatible Modules | Yokogawa FIO communication modules, power supply modules, and bus interface modules |
| Compatible Systems | Yokogawa CENTUM VP, CENTUM CS 3000, FIO Systems |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Relative Humidity | 10% to 90% RH (Non-condensing) |
| Application | Distributed control systems (DCS) for oil & gas, petrochemical, power generation, LNG, chemical processing, and other continuous process industries |
| Dimensions | Approx. 482.6 × 205 × 160 mm |
| Weight | Approx. 12 kg |
| Condition | New and original |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the Yokogawa ANB11D-225 used for?
The ANB11D-225 serves as an Optical ESB Bus Node Unit that connects Field Control Units (FCUs) with FIO I/O modules over a dual-redundant optical communication network, ensuring reliable data exchange in Yokogawa DCS systems.
Q2: Which Yokogawa systems are compatible with the ANB11D-225?
It is designed for CENTUM VP, CENTUM CS 3000, and other Yokogawa FIO-based distributed control systems that utilize the Optical ESB Bus architecture.
Q3: What are the key features of the ANB11D-225?
The unit provides dual-redundant Optical ESB Bus communication, supports redundant power supplies, accommodates 19-inch rack mounting, and can be configured with optical repeater modules for extended communication distances.
Q4: What are the dimensions and weight of the ANB11D-225?
The node unit has approximate dimensions of 482.6 × 205 × 160 mm and weighs approximately 12 kg.
Q5: What is the purpose of the dual-redundant Optical ESB Bus?
The redundant architecture maintains uninterrupted communication by automatically switching to the standby communication path if the primary path fails, improving overall system availability.
Q6: Does the ANB11D-225 support optical repeaters?
Yes. The -225 configuration supports 5 km optical repeater operation, making it suitable for long-distance communication between control equipment and field I/O stations.
Q7: What should be checked before installing the ANB11D-225?
Before installation, verify the rack configuration, power supply specification, optical ESB Bus network design, compatible FIO modules, communication modules, and environmental conditions.
Q8: What are the advantages of the Yokogawa ANB11D-225?
The ANB11D-225 offers highly reliable redundant communication, easy integration with Yokogawa CENTUM systems, support for long-distance optical networks, flexible rack installation, and dependable long-term operation in mission-critical industrial applications.
