Technical Specifications
| Parameter | Specification |
|---|---|
| Input Signal | 4–20 mA |
| Channels | 8 (independently isolated) |
| Maximum Input Current | 22.5 mA |
| Dielectric Strength | AC 1500 V |
| Input Resistance | 2-wire: 400–750 Ω 4-wire: 485–925 Ω |
| Accuracy | ±16 µA |
| Step Response Time | 100 ms |
| Data Update Rate | 10 ms |
| Transmitter Power Output | ≥16 V DC (max 20 mA) |
| Maximum Input Voltage (4-wire) | 25 V |
| Temperature Drift | ±16 µA/10°C |
| Maximum Current Consumption | 5 V DC: 150 mA 24 V DC: 450 mA |
| Terminal Type | Crimp Terminal (ATSA3□) |
| HART Communication | Supported |
| Operating Temperature | -20°C to +70°C |
| Dimensions | 130 × 107.5 × 32.8 mm |
| Weight | 0.3 kg |
FAQ
FAQ
-
What is the isolation performance of this module?
Each channel of the ASI133-H00 is independently isolated and can withstand AC 1500 V, ensuring secure signal transmission and strong interference immunity. -
What input signal types are supported?
The module supports standard 4–20 mA current input only; voltage input is not supported. -
Is the response time suitable for high-dynamic control systems?
The module has a step response time of 100 ms, suitable for most process control applications. Ultra-fast control loops should be evaluated according to system requirements. -
What are the applications of HART communication?
Supports HART for transmitter diagnostics, parameter configuration, and status monitoring, enhancing maintenance efficiency. -
Will accuracy degrade in high-temperature environments?
Temperature drift is ±16 µA/10°C, maintaining stable accuracy within the -20°C to +70°C range. -
How to prevent signal interference among multiple channels?
Independent channel isolation and shielded wiring effectively prevent cross-channel interference. -
Does the module’s power consumption affect system load?
Maximum current consumption is 5 V DC: 150 mA, 24 V DC: 450 mA; ensure sufficient system power supply. -
Are the module’s dimensions and weight suitable for compact control cabinets?
Dimensions are 130 × 107.5 × 32.8 mm, weight 0.3 kg, compatible with most compact control cabinets.
