Technical Specifications
| Parameter | Description |
|---|---|
| Model | CP701-S1 |
| System | CENTUM CS 1000 (for small and medium-sized plants) |
| Architecture | Same as CENTUM CS system |
| Processor | R4300 MPU, internal clock 75 MHz, external clock 25 MHz |
| Main Memory | 8 MB ECC DRAM |
| Flash | Programmable Flash for boot program |
| Cache | 16 KB instruction cache, 8 KB data cache |
| Address Space | 4 GB (32-bit mode) |
| Data Width | Supports 32-bit, 16-bit, 8-bit data |
| Communication Bus | VLnet (10 Mbps, 10BASE2, BNC connector, up to 185 m/seg) |
| Max Stations | 24 (max 16 FCS, 8 HIS) |
| Redundancy | CPU, power supply, VLnet interface, I/O bus all support redundancy |
| Hot Swap | Redundant units support hot swap, easy maintenance |
| Power Input | 100-120 V AC, 220-240 V AC, 24 V DC (selectable) |
| Internal Power | +5 V DC |
| Compliance | EN55011 Class A, EN50082-2, EN61010-1, CSA-C22.2 No.1010.1 |
| Dimensions | 190 x 120 x 32.8 mm |
| Weight | 0.3 kg (CPU card), 0.7 kg (typical configuration) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of power input are supported by the CP701-S1?
A1: It supports 100-120 V AC, 220-240 V AC, and 24 V DC selectable power input.
Q2: What is the main memory capacity of the CP701-S1?
A2: It is equipped with 8 MB ECC DRAM for high-reliability data storage.
Q3: Does the CPU support redundancy?
A3: Yes, redundancy is available for the CPU card, power supply, VLnet interface, and I/O bus.
Q4: What are the main application areas for CP701-S1?
A4: It is mainly used in distributed control systems for small and medium-sized plants, especially where high reliability and easy maintenance are required.
Q5: What are the dimensions and weight of the CP701-S1?
A5: Dimensions are 190 x 120 x 32.8 mm; CPU card weight is 0.3 kg, typical unit weight is about 0.7 kg.
Q6: What communication bus is used by the CP701-S1?
A6: VLnet bus is used, with 10 Mbps speed, 10BASE2 coaxial cable and BNC connector.
Q7: Is maintenance convenient for CP701-S1?
A7: Yes, redundant units support hot swap, and all modules are front-insertable for easy replacement and maintenance.
Q8: Which international standards does the CP701-S1 comply with?
A8: It complies with EMC and safety standards including EN55011, EN50082-2, EN61010-1, and CSA-C22.2 No.1010.1.
