Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | EB501-10 |
| Product Type | ER Bus Interface Slave Module |
| Applicable System | CENTUM CS 3000 |
| Communication Method | ER bus for FIO, remote node connection |
| Bus Type | ER bus |
| Max Remote Nodes | Up to 14 (enhanced database), up to 9 (standard configuration) |
| Bus Transmission Speed | 10 Mbps |
| Bus Topology | Bus topology |
| Transmission Distance | Max 185 m (YCB141 coaxial cable, varies with repeaters) |
| Transmission Cable | YCB141, YCB311 coaxial cable |
| Bus Redundancy | Supported (optional) |
| Dimensions | 144.65 x 130 x 32.8 mm |
| Weight | 0.3 kg |
| Operating Temperature | 0 – 50°C |
| Storage Humidity | 10% – 90% RH (no condensation) |
| Mounting Method | 19-inch rack/special cabinet |
| Compliance | CSA, CE, FM and other industrial standards |
FAQ
FAQ (Frequently Asked Questions)
Q1: What is the main function of the EB501-10?
A1: The EB501-10 functions as an ER bus interface slave module, enabling high-speed data communication between the FCS and remote nodes.
Q2: How many remote nodes does the EB501-10 support?
A2: It supports up to 14 remote nodes with an enhanced database, and up to 9 with the standard configuration.
Q3: Does the module support redundant communication?
A3: Yes, ER bus redundancy is supported to improve system reliability.
Q4: What is the maximum transmission distance for the ER bus?
A4: The maximum is 185 meters per segment using YCB141 coaxial cable, subject to configuration and repeater count.
Q5: Which systems is the EB501-10 compatible with?
A5: It is designed for use in Yokogawa CENTUM CS 3000 production control systems with FIO architecture.
Q6: What are the installation environment requirements for the EB501-10?
A6: Operating temperature is 0–50°C, humidity is 10%–90% RH (non-condensing), and installation is in a 19-inch rack or dedicated cabinet.
Q7: What are the module’s dimensions and weight?
A7: Dimensions are 144.65 x 130 x 32.8 mm, and weight is 0.3 kg.
Q8: Which industrial standards does this module comply with?
A8: The module is certified to CSA, CE, FM, and other international industrial safety and EMC standards.
