Technical Specifications
| Parameter | Description |
|---|---|
| Input Channels | 8 channels (differential input) |
| A/D Resolution | 12-bit |
| Conversion Speed | 1ms per channel |
| Input Signal Range | 0–5V DC / 1–5V DC / 0–10V DC / -10–+10V DC |
| Input Impedance | ≥1MΩ |
| Scaling Range | Adjustable from -30,000 to 30,000 |
| Filter Function | First-order delay filter or moving average, configurable per channel |
| Peak/Valley Data Hold | Supports recording of maximum and minimum values |
| Self-diagnosis | Hardware diagnostics and overrange detection supported |
| Isolation | Input terminals optically isolated from internal circuits |
| Power Consumption | 210mA (5V DC) |
| External Connection Terminals | 18-pin terminal block (M3.5 screws) |
| Dimensions | 28.9 × 100 × 106.1 mm |
| Weight | 0.2 kg |
FAQ
FAQ
Q1: What types of input signals does the F3AD08-5V support?
A1: Supports voltage-type input signals: 0–5V DC, 1–5V DC, 0–10V DC, and -10–+10V DC. Each channel can be configured individually.
Q2: What is the A/D conversion accuracy of the module?
A2: The module uses a 12-bit A/D converter, providing high-precision analog signal acquisition.
Q3: How is the scaling range configured for each channel?
A3: The scaling range can be set from -30,000 to 30,000, allowing proper mapping of input signals to internal system values.
Q4: Does the F3AD08-5V have self-diagnosis capabilities?
A4: Yes, it supports hardware diagnostics and can detect overrange or abnormal input conditions.
Q5: Can the module record peak and valley values?
A5: Yes, each channel can record maximum and minimum values for signal monitoring.
Q6: How is the filter function configured?
A6: The module provides first-order delay filtering or moving average calculation, configurable per channel.
Q7: What is the isolation method of the module?
A7: The input terminals are optically isolated from internal circuits to enhance system noise immunity and safety.
Q8: What are the dimensions and weight of the module?
A8: Dimensions are 28.9 × 100 × 106.1 mm, and the weight is approximately 0.2 kg, suitable for installation in standard FA-M3 racks.
