Technical Specifications
| Parameter | Specification |
|---|---|
| Model | F3LE11-0T |
| Product Name | Ethernet Interface Module |
| Network Interface | 10BASE-T / 100BASE-TX |
| Communication Protocols | TCP, UDP, IP, ICMP, ARP, SMTP, POP3, HTTP |
| Data Format | ASCII / Binary (switch selectable) |
| Write Protection | Enabled/Disabled (switch selectable) |
| Loopback Test Mode | Available (switch selectable) |
| IP Address Configuration | Via rotary hexadecimal switches |
| Transmission Speed | 10 Mbps / 100 Mbps |
| Max Cable Length | 100 m (for twisted-pair cable) |
| Operating Temperature | 0 °C to 55 °C |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Temperature | -20 °C to 75 °C |
| Storage Humidity | 10% to 90% RH (non-condensing) |
| Dimensions | 28.98 × 100 × 83.2 mm |
| Weight | 0.13 kg |
| Compatible CPU Modules | F3SP05, F3SP08, F3SP21, F3SP25, F3SP28, F3SP35, etc. |
| Mountable Modules (Max) | Up to 6 (varies by CPU module) |
FAQ
FAQ
Q1: What type of network cable does the F3LE11-0T support?
A1: It supports twisted-pair cables compatible with 10BASE-T and 100BASE-TX Ethernet standards.
Q2: How is the IP address configured for the F3LE11-0T module?
A2: The IP address is set using 16-position rotary hexadecimal switches located on the module.
Q3: Does the F3LE11-0T support write protection?
A3: Yes, write protection can be enabled or disabled via the onboard condition setting switches.
Q4: Can I use the F3LE11-0T in environments with corrosive gases?
A4: No, the module must be installed in environments free from corrosive gases, flammable gases, and heavy dust.
Q5: What communication protocols are supported?
A5: It supports TCP, UDP, IP, ICMP, ARP, SMTP, POP3, and HTTP protocols.
Q6: Is the module suitable for high-vibration environments?
A6: Yes, but proper securing methods must be applied according to the user manual for vibration resistance.
Q7: Can the module be used for e-mail-based communication?
A7: Yes, it supports sending data via e-mail either from a sequence program or through automatic CPU monitoring.
Q8: How many F3LE11-0T modules can be installed in one system?
A8: A maximum of six can be installed, depending on the CPU model (e.g., F3SP25 and higher support more modules).
