Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Relay Output Module |
| Model Number | NFDR541 |
| Function | Provides relay-based digital output for Yokogawa control systems |
| Output Channels | 8 channels (relay contacts) |
| Output Type | Form A (SPST-NO) or Form C (SPDT) contacts |
| Contact Rating | 250 V AC / 2 A, 30 V DC / 2 A (resistive load) |
| Isolation | Optical and relay isolation between field and system |
| Switching Speed | ≤ 10 ms |
| Status Indication | Individual channel LED indicators |
| Power Supply | Supplied via system backplane |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 70 °C |
| Humidity | 10% to 90% RH, non-condensing |
| Dimensions | 130 x 111.5 x 32.8 mm |
| Weight | 0.3 kg |
| Mounting | Rack-mounted |
| Applications | Industrial automation, interlock control, alarm signaling, device actuation |
FAQ
FAQ
Q1: What is the function of the NFDR541 Relay Output Module?
It provides relay-based digital output for controlling external devices.
Q2: How many output channels does the NFDR541 have?
It has 8 relay output channels.
Q3: What type of relay contacts does it use?
It uses Form A (SPST-NO) or Form C (SPDT) relay contacts.
Q4: What is the maximum contact rating?
250 V AC / 2 A or 30 V DC / 2 A for resistive loads.
Q5: Does the module provide isolation?
Yes, it provides optical and relay isolation between field signals and the system.
Q6: What is the typical switching speed of the relays?
The switching time is typically ≤ 10 ms.
Q7: What are the dimensions and weight of the NFDR541 module?
Dimensions: 130 x 111.5 x 32.8 mm; Weight: 0.3 kg.
Q8: In what applications is the NFDR541 commonly used?
It is used for interlock control, alarm signaling, and actuation of external devices in industrial automation.
