Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SAI143 |
| Number of Input Channels | 16 channels, module isolation |
| Rated Input Range | 4 to 20 mA |
| Permissible Input Range | 0 to 25 mA |
| Input Impedance (Power ON) | 250 Ω + voltage drop (varies 272.5–362.5 Ω) |
| Input Impedance (Power OFF) | ≥500 kΩ |
| Rated Accuracy | ±16 µA (Input range 1 to 23 mA or 0.05 to 23 mA depending on type) |
| Data Update Frequency | 40 ms |
| Temperature Drift | ±16 µA/10 °C |
| Transmitter Power Supply | 16.15 V min (at 20 mA), 26.4 V max (at 0 mA), current limit 25 mA |
| 2/4-wire Setting | Individual channel configurable |
| Withstand Voltage | 1.5 kV AC between input and system for 1 minute |
| Maximum Current Consumption | 5V: 320 mA; 24V: 550 mA |
| External Connection | Pressure clamp terminal / MIL cable / dedicated signal cable |
| Dimensions | 130 × 107.5 × 32.8 mm |
| Weight | Approx. 0.34 kg (pressure clamp/MIL) / Approx. 0.39 kg (with signal adapter) |
| Data Update Frequency | 40 ms |
| PRM Support | Available on SAI143-H |
| Transmitter Power ON/OFF Function | Available (in 2-wire setting, all 16 channels simultaneously) |
FAQ
FAQ
Q1: What input signal range does the SAI143 support?
A1: The module supports standard 4 to 20 mA input signals, with a permissible range of 0 to 25 mA.
Q2: How many input channels does each module provide?
A2: Each SAI143 module provides 16 isolated input channels.
Q3: What is the rated accuracy of the module?
A3: The rated accuracy is ±16 µA within 1–23 mA or 0.05–23 mA input range (depending on model).
Q4: Does the module support HART communication?
A4: Yes, the SAI143-H model supports HART communication.
Q5: What is the input impedance of the module?
A5: Input impedance is 250 Ω plus internal voltage drop when powered on, and ≥500 kΩ when powered off.
Q6: Can the module be configured for 2-wire or 4-wire?
A6: Yes, each channel can be individually set to 2-wire or 4-wire mode.
Q7: What is the withstand voltage of the module?
A7: The module can withstand 1.5 kV AC between input and system for one minute.
Q8: What are the dimensions and weight of the module?
A8: The module measures 130 × 107.5 × 32.8 mm and weighs approx. 0.34 kg (pressure clamp/MIL), or approx. 0.39 kg with signal adapter.
