Technical Specifications
| Parameter | Specification |
|---|---|
| Number of Input Channels | 16 channels with module isolation |
| Input Signal Type | 4–20 mA current signals |
| Input Impedance | Power-ON: 250 Ω + current value Power-OFF: ≥500 kΩ |
| Rated Accuracy | ±16 µA (1–23 mA input range) |
| Data Update Frequency | 40 ms |
| Withstanding Voltage | 1.5 kV AC between input signal and system for 1 min |
| Operating Temperature | -20 to 70°C (ISA Standard G3) |
| Transmitter Power Supply | 16.15 V min at 20 mA, 26.4 V max at 0 mA |
| Transmitter Power Supply ON/OFF | Available for all 16 channels simultaneously in 2-wire mode |
| Module Isolation | Yes, prevents ground loops and electrical noise |
| Dimensions | 130 × 107.5 × 32.8 mm |
| Weight | 0.34 kg |
FAQ
FAQ
-
Q1: What is the maximum input current range supported by SAI143-S03/K4A00?
A1: The module supports 4–20 mA standard current signals, with a measurement accuracy of ±16 µA within 1–23 mA range. -
Q2: Can this module operate in extreme temperatures?
A2: Yes, it operates safely within -20°C to 70°C, complying with ISA Standard G3. -
Q3: How is electrical isolation achieved in this module?
A3: Each channel is isolated, preventing ground loops and minimizing interference from external electrical noise. -
Q4: What is the update rate of analog input data?
A4: The module updates input data every 40 milliseconds, allowing near real-time monitoring. -
Q5: Can the transmitter power supply be controlled independently for each channel?
A5: No, the ON/OFF function for transmitter power supply is available simultaneously for all 16 channels in 2-wire configuration. -
Q6: What protection does the module have against voltage surges?
A6: It can withstand 1.5 kV AC between input signal and system for 1 minute. -
Q7: What are the physical dimensions and weight of the module?
A7: The module measures 130 × 107.5 × 32.8 mm and weighs 0.34 kg. -
Q8: How is the input impedance affected during power-off?
A8: During power-off, the input impedance is ≥500 kΩ, preventing signal leakage and protecting connected devices.
