Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SAV144 |
| Number of Input Channels | 16 channels, module isolation |
| Rated Input Range | 1 to 5 V / 1 to 10 V |
| Permissible Input Range | ±30 V |
| Input Impedance (Power-ON) | 1 MΩ |
| Input Impedance (Power-OFF) | 100 kΩ |
| Rated Accuracy | 1–5 V: ±4 mV / 1–10 V: ±9 mV |
| Data Update Frequency | 40 ms |
| Temperature Drift | 1–5 V: ±4 mV/10 °C / 1–10 V: ±9 mV/10 °C |
| Withstand Voltage | 1.5 kV AC (1 minute) |
| Maximum Current Consumption | 5 V system: 300 mA / 24 V system: 140 mA |
| External Connection | Pressure clamp terminal, MIL cable, dedicated signal cable (KS1) |
| Dimensions | 130 × 124 × 32.8 mm |
| Weight | Approx. 0.29 kg |
FAQ
FAQ
Q1: How many input channels does the SAV144 support?
A1: The SAV144 supports 16 isolated input channels.
Q2: What is the input voltage range of this module?
A2: The rated input range is 1–5 V or 1–10 V, with a permissible range of ±30 V.
Q3: What is the input impedance of the module?
A3: The input impedance is 1 MΩ when powered on and 100 kΩ when powered off.
Q4: What is the accuracy of the SAV144?
A4: Accuracy is ±4 mV for 1–5 V and ±9 mV for 1–10 V.
Q5: How often does the module update data?
A5: The data update frequency is every 40 milliseconds.
Q6: What is the withstand voltage capability of the module?
A6: It can withstand 1.5 kV AC between the input signal and system for 1 minute.
Q7: What are the dimensions and weight of the SAV144?
A7: The dimensions are 130 × 124 × 32.8 mm, and the weight is approximately 0.29 kg.
Q8: Can the SAV144 be used in a dual-redundant configuration?
A8: Yes, the SAV144 supports dual-redundant configuration.
