Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Yokogawa Electric Corporation |
| Product Model | SC200S |
| Product Type | Intelligent Conductivity Transmitter |
| Series | SC200 Series |
| Function | Continuous online conductivity and temperature measurement for industrial process control |
| Measurement Principle | 2-electrode conductivity measurement |
| Measured Parameters | Conductivity and Temperature |
| Conductivity Range | Up to 2000 mS/cm (depending on sensor and cell constant) |
| Cell Constant Compatibility | 0.01 to 50.0 cm⁻¹ |
| Temperature Compensation | Automatic or Manual |
| Temperature Sensor Input | Pt100, Pt1000, NTC |
| Output Signal | 4–20 mA DC (2-wire loop-powered) |
| Power Supply | 24 VDC (Loop-powered) |
| Display | LCD Digital Display |
| Enclosure Protection | IP65 |
| Mounting | Panel, Wall, or Pipe Mount |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -30°C to +70°C |
| Application | Water treatment, chemical processing, power generation, pharmaceutical, food & beverage, and wastewater treatment |
| Dimensions | Approx. 144 × 144 × 150 mm |
| Weight | Approx. 1.6 kg |
| Condition | New and original (Discontinued) |
| Warranty | 12 months |
FAQ
FAQ
Q1: What is the Yokogawa SC200S Intelligent Conductivity Transmitter used for?
The SC200S is designed for continuous online monitoring of conductivity and temperature in industrial liquid processes. It helps optimize process control and improve product quality in a wide range of applications.
Q2: Which industries commonly use the SC200S?
The transmitter is widely used in water and wastewater treatment, power plants, chemical processing, pharmaceuticals, food and beverage production, and other industries that require reliable conductivity measurement.
Q3: Does the SC200S support automatic temperature compensation?
Yes. The transmitter supports both automatic and manual temperature compensation, ensuring accurate conductivity measurements under varying process temperatures.
Q4: What are the dimensions and weight of the SC200S?
The unit has approximate dimensions of 144 × 144 × 150 mm and weighs approximately 1.6 kg.
Q5: Which sensors are compatible with the SC200S?
The transmitter supports Yokogawa conductivity sensors with cell constants ranging from 0.01 to 50.0 cm⁻¹ and temperature sensors such as Pt100, Pt1000, and NTC.
Q6: What output signal does the SC200S provide?
The SC200S provides a 4–20 mA DC loop-powered output, allowing seamless integration with PLC, DCS, and other industrial control systems.
Q7: What should be checked before installing the SC200S?
Before installation, verify the conductivity sensor type, cell constant, power supply, mounting location, wiring, and environmental conditions to ensure proper operation.
Q8: What are the advantages of the Yokogawa SC200S Intelligent Conductivity Transmitter?
The SC200S offers stable conductivity measurement, automatic temperature compensation, low maintenance requirements, simple two-wire installation, reliable industrial performance, and easy integration into process automation systems.
